Pyle PMHM2 User Manual

General
PYLE PMHMS20/PMHM2 mini headset microphone is ideally suited for vocal
sound and speech application which requires much freedom of movement.
The unique tiny size and super light weight provides a comfortable and optimum
fit for any occasion.
Such as dance and sports instructors, Great for video use ,the mini microphone
is practically invisible.
The microphone ensures a perfect blend of the microphone for discreet
appliance.
It is available in Skin and Black Color.
Features
High quality back electret condenser capsule
Flat frequency response and superior EMI suppression
-
Omni directional polar pattern
Easy to wear headband
Easy fit foam windscreen
General rules for use
1. Place the headband around the back of the head.
2. Aim the microphone toward the corner of the speakers mouth.
3. Connect the microphone to the appropriate wireless headset.
4. Always use the supplied foam windscreen to control breath noise
Connectors
Connectors:
SHURE type 4pin mini XLR
Standard 3.5mm plug
1/4''Atapter
Accessories
Accessories: windscreen
PYLE AUDIO INC.
Address: 1600 63rd.Street Brooklyn N.Y. 11204,USA
Tel: 718-535-1800, 1-888-318-PYLE
Fax: 718-236-2400
URL: http://www.pyleaudio.com
E-mail: sales@pyleaudio.com
2012-PYLEAUDIO-PMHMS20-PMHM2-A0001
Specifications
Model...........................................................................PMHMS20/PMHM2
Element........................................................................Back Electret Condenser
Polar Pattern...............................................................Omni-directional
Frequency Response....................................................20Hz- 20KHz
Sensitivity...................................................................-45dB± 3dB
Output Impedance.......................................................2000Ω ± 30%
Max.Input SPL.............................................................130dB
S/N Ratio.....................................................................>70dB
Power Supply................................................................1.5V-10V
Cable............................................................................Φ1.5*1.2M
Dimension....................................................................Φ5mm
Color............................................................................Skin
Connector..............................................(PMHMS20)SHURE type 4pin mini XLR
(PMHM2)Standard 3.5mm plug+1/4''Atapter
Accessories.................................................................Windscreen
Figure 1: Polar pattern
Figure 2: Frequency response
PMHMS20
PMHM2
MINI HEADSET MICROPHONES
USER MANUAL
