Blaze King KING KT1102 Owner's Manual

Non-catalytic solid fuel wood heaters
Hide thumbs
Table of Contents

Advertisement

Quick Links

BLAZE KING
OWNERS MANUAL
MODELS
KING KT1102
PRINCESS PT1003
NON-CATALYTIC
SOLID FUEL WOOD HEATERS

SAVE THESE INSTRUCTIONS

VALLEY COMFORT SYSTEMS INC.
1290 COMMERCIAL WAY
PENTICTON, B.C.
V2A 3H5
PHONE (250) 493-7444
Pour la version française de nos manuels S.V.P. vous référez à notre site web :
www.blazeking.com/product-manuals.html
Date Printed: February 15, 2008
Version 1.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KING KT1102 and is the answer not in the manual?

Questions and answers

Related Manuals for Blaze King KING KT1102

Summary of Contents for Blaze King KING KT1102

  • Page 1: Save These Instructions

    BLAZE KING OWNERS MANUAL MODELS KING KT1102 PRINCESS PT1003 NON-CATALYTIC SOLID FUEL WOOD HEATERS SAVE THESE INSTRUCTIONS VALLEY COMFORT SYSTEMS INC. 1290 COMMERCIAL WAY PENTICTON, B.C. V2A 3H5 PHONE (250) 493-7444 Pour la version française de nos manuels S.V.P. vous référez à notre site web : www.blazeking.com/product-manuals.html...

  • Page 2: Table Of Contents

    INDEX ASH ..................................10, 13 CATALYTIC COMBUSTOR ............................5 CAUTION ................................10, 18 CHILDREN ................................9, 16 CHIMNEY......................3, 7, 8, 10, 16, 17, 18, 19, 21, 23, 24 Chimney fire ................................17 CLEANING ................................15 CLEARANCES ............................... 9, 22, 23 COMBUSTIBLE MATERIAL ..........................
  • Page 3 SAFETY NOTICE IF THE BLAZE KING STOVE IS NOT PROPERLY INSTALLED AND OPERATED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTALLATION DIRECTIONS. CONTACT LOCAL BUILDING FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. THIS...
  • Page 4 If you have any questions that are not answered here, contact your BLAZE KING dealer, Local Building Inspector, Fire Department, or our customer service department at Blaze King/Valley Comfort Systems Inc. 250-493-7444. We do not accept collect phone calls at the factory.

  • Page 5: Catalytic Combustor

    If this product requires repair or replacement due to defects in material or workmanship covered by this warranty, contact your BLAZE KING dealer and explain the defect. If the dealer does not repair or replace the product to your satisfaction, contact the Service Department of VALLEY COMFORT SYSTEMS at 1-250-493-7444 or write to 1290 Commercial Way, Penticton, BC, V2A 3H5.
  • Page 6 WARNING TO VALIDATE THIS WARRANTY, YOU MUST COMPLETE AND RETURN THE WARRANTY CARD WITH 20 DAYS OF THE DATE OF PURCHASE Blaze King is proudly manufactured in Canada by: VALLEY COMFORT SYSTEMS INC. 1290 COMMERCIAL WAY PENTICTION, BRITISH COLUMBIA V2A 3H5...

  • Page 7: Combustible Material

    DEFINITIONS CHIMNEY One or more passageways, vertical or nearly so, for sending flue gases (smoke) to the outside atmosphere. You must ensure proper clearances are maintained from combustible materials. CHIMNEY CONNECTOR Also known as stove pipe. Connects a fuel-burning appliance to a chimney. A chimney connector shall not pass through an attic or roof space, closet or similar concealed space, or a floor, ceiling, wall or partition of combustible construction.

  • Page 8: Chimney Fire

    MOBILE HOME A residence mounted on wheels, or capable of having wheels installed for moving to another location. Frequently referred to as "Manufactured Homes" to differentiate between travel trailers and more permanent residences. KT & PT MODELS ARE NOT APPROVED FOR MOBILE HOME APPLICATIONS.

  • Page 9: Inspection 3

    A masonry chimney that is damaged should be repaired or rebuilt. Contact your Fire Department for further advice. Your family should have a prearranged plan so that each person will know what to do and will act immediately if such an emergency arises. BUILDING AND FIRE CODES, PERMITS, AND INSPECTIONS.

  • Page 10: Creosote

    When selecting wood for your Blaze King stove it is preferable that you use seasoned wood. Dry, seasoned wood will burn cleaner and produce less creosote. Dry or small pieces of fuel will provide a hotter fire. Larger pieces can be used to provide a longer burn time.

  • Page 11: Operation

    DOOR GASKET & GLASS Check the loading door gasket for deterioration at least twice each heating season. Inspect the gasket for physical deterioration missing sections or obvious leakage. To check the gasket further, insert a piece of paper into the door opening and close and latch the door. Obvious resistance should be felt when pulling the paper out.
  • Page 12 COMBUSTION AIR CONTROL - OPTIMUM SETTING LOADING OR RELOADING 1. Temperature adjustments. Adjustments to achieve the desired room temperature should be made in small increments for the most effective clean-burning operation. After a few days you will know where to set your thermostat to deliver just the heat you require. Small hot fires produce less creosote than large smoldering fires.
  • Page 13 Your local BLAZE KING dealer is your authorized service representative. Should you have any problems with operating or maintaining your BLAZE KING STOVE, contact your dealer as soon as possible. The dealer will help you solve operating problems, provide replacement parts, and/or arrange warranty service repairs if required.

  • Page 14: Door Catch

    3) Clean out the channel so the new gasket can fit smoothly. 4) Run a small bead of a door gasket adhesive (see your Blaze King dealer) or high temperature silicone adhesive along the center of the channel. Start the new gasket in the lower right corner. Do not stretch or cut the gasket.

  • Page 15: Gold Door

    5) Install the replacement glass gasket around the outer perimeter. Place the glass in the door frame. Be sure the words "Blaze King" etched in the glass reads correctly when the door is closed. 6) Install the retainers with the 10 x 3/8" screws. A drop of penetrating oil on each screw will facilitate easy installation.

  • Page 16: Excessive Creosote

    Contact a qualified electrical contractor for repair of electrical systems. TROUBLESHOOTING Your Blaze King is designed to allow a wide selection of heat output levels. If you begin to lose control of the amount of heat the stove is emitting, determine the problem early so that major problems can be avoided.

  • Page 17: Fans Will Not Run

    Consult your Blaze King dealer. Poor draft caused by an oversize flue Measure draft with Manometer. See CHECK YOUR CHIMNEY (Page 19) Consult your Blaze King dealer or a chimney sweep. Strong, gusting winds causing downdraft in chimney Install wind-resistant chimney cap.

  • Page 18: Preparation And Assembly

    Pine PREPARATION AND ASSEMBLY WARNING IMPROPER ASSEMBLY AND/OR INSTALLATION OF YOUR BLAZE KING WOODSTOVE OR FAILURE TO OPERATE IT ACCORDING TO THE GUIDELINES DETAILED IN THESE INSTRUCTIONS, WILL VOID THE STOVE WARRANTY, CAN CAUSE A HOUSE OR CHIMNEY FIRE, AND MAY ENDANGER YOUR FAMILY.

  • Page 19: Stove Placement

    PLANNING FOR YOUR STOVE PLACEMENT As you plan your installation, consider the following; 1) Stove should be placed as central in the home as possible. consider safety, convenience and traffic flow. 2) Minimum clearances shown in figure 3 must be adhered to. The stove and chimney connector may be placed closer to the wall than shown in figure 3 if the wall is properly protected.
  • Page 20 You can obtain an outside air kit from your Blaze King dealer, which when properly installed will ensure adequate combustion air. In mobile home installations (only the catalytic model is mobile home approved), you must use the outside air kit.

  • Page 21: Chimney Connector

    FLOOR PROTECTOR The stove must be placed on a floor protector if the floor is wood or other combustible flooring. Any non- combustible material or a listed floor protector is acceptable. To provide the proper clearances, the floor protector must be at least 18"...
  • Page 22 COMBUSTIBLE MATERIAL FLOOR PROTECTION FIGURE 3 MODEL KING KT 1102 (non catalytic) ROOF OR WALL EXIT CLEARANCES ARE THE SAME FOR WALL EXIT CLEARANCE ABOVE HORIZONTAL CONNECTOR 18" Parallel & corner 14" 7" 25" 14.5" 12" 23.5" Parallel reduced side use side shields 8"...
  • Page 23 MODEL PRINCESS PT1003 (non catalytic) ROOF OR WALL EXIT CLEARANCES ARE THE SAME FOR WALL EXIT CLEARANCE ABOVE HORIZONTAL CONNECTOR 18" Parallel & corner 12" 7" 22" 14.5" 11" 22.5" Parallel reduced side use side shields 7" 7" 17" 14.5" Parallel &...
  • Page 24 Horizontal runs should be as short as possible and slope up 1/4" per foot run. 2) The chimney connector must not penetrate a combustible wall without using an acceptable thimble system. Check with your Blaze King dealer, your building inspector or a fire protection officer for local requirements 3) Mark the exact location for the floor protection.
  • Page 25 PRINCESS PT1003 BRICK INFORMATION BRICK SIZES 4.50" 2.00" 4.50" 2.00" 4.50" 2.00" 9.00" 9.00" 7.625 7.625 6.375 6.375 BACK LEFT SIDE RIGHT SIDE BOTTOM FRONT BAFFLE Date Printed: February 15, 2008 Version 1.01...
  • Page 26 KING KT BRICK INFORMATION BRICK DIMENSIONS BACK LEFT RIGHT SIDE SIDE BOTTOM FRONT BAFFLE Date Printed: February 15, 2008 Version 1.01...
  • Page 27 Date Printed: February 15, 2008 Version 1.01...
  • Page 28 Date Printed: February 15, 2008 Version 1.01...
  • Page 29 Date Printed: February 15, 2008 Version 1.01...

This manual is also suitable for:

Princess pt1003
