Blaze King CLARITY 26.FS.IPI Operation & Installation Manual

Freestanding direct vented gas room heater with intermittent pilot ignition (ipi) for use with natural gas or lpg

Advertisement

CLARITY 26.FS.IPI
FREESTANDING DIRECT VENTED GAS ROOM HEATER
with Intermittent Pilot Ignition (IPI)
For use with natural gas (NG) or propane (LPG)
WARNING:
If the information in these
OPERATION &
instructions are not followed exactly, a fi re
INSTALLATION
or explosion may result causing property
MANUAL
damage, personal injury or loss of life.
4011009
5007099
Date Installed: ____________
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Serial No.: _____________
Homeowner: Please keep these instructions for future reference.
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
180.OM.CL26.FS.IPI E v1.02
September 6, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLARITY 26.FS.IPI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blaze King CLARITY 26.FS.IPI

  • Page 1 CLARITY 26.FS.IPI FREESTANDING DIRECT VENTED GAS ROOM HEATER with Intermittent Pilot Ignition (IPI) For use with natural gas (NG) or propane (LPG) WARNING: If the information in these OPERATION & instructions are not followed exactly, a fi re INSTALLATION or explosion may result causing property MANUAL damage, personal injury or loss of life.
  • Page 2: Table Of Contents

    PARTS LIST ______________________________________________________________________________ 49 TROUBLESHOOTING ____________________________________________________________________ 50 WARRANTY ______________________________________________________________________________ 53 Manufactured By Valley Comfort Systems Inc. Blaze King Industries 1290 Commercial Way 146 A Street Penticton, BC V2A 3H5 Walla Walla, WA 99362 CANADA U.S.A. Phone: 250-493-7444 Phone: (509) 522-2730...
  • Page 3: Safety Precautions

    Clarity 26 FS IPI Page 3 SAFETY PRECAUTIONS This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes. FIRE OR EXPLOSION HAZARD Failure to follow safety warnings This appliance is only for use with the type of gas exactly could result in serious injury, indicated on the rating plate.
  • Page 4: Your Safety

    Page 4 Clarity 26 FS IPI SAFETY PRECAUTIONS cont. YOUR SAFETY • Have the venting system inspected annually by a qualifi ed installer for blockage and signs of deterioration. • To prevent injury, do not allow anyone who is unfamiliar with the stove to operate it. •...
  • Page 5: General Information

    Vent, Selkirk, Security or American Metal Products vent components. SPECIFICATIONS MODEL Natural Gas (NG) Propane (LPG) CLARITY 26.FS.IPI Manifold Pressure 3.8 in. w.c. (0.95kPa) 10.6 in. w.c. (2.64 kPa) Min. Supply Pressure for 7 in. w.c. (1.74 kPa) 11.0 in. w.c. (2.74 kPa) Purpose of Input Adjustment Orifi...
  • Page 6: Certification Label

    MANUFACTURE DATE MANUFACTURED IN: JAN  FEB  MAR  APR  MAY  JUN   USA: Blaze King Industries  CANADA: Valley Comfort Systems JUL  AUG  SEP  OCT  NOV  DEC  146A Street, Walla Walla, WA. 99362 1290 Commercial Way, Penticton, B.C.
  • Page 7: Dimensions

    Clarity 26 FS IPI Page 7 DIMENSIONS NOTE: RATING AND LIGHTING INSTRUCTION LABELS ARE LOCATED ON THE LOWER RIGHT AND LEFT OUTSIDE PANELS. TO REMOVE, LIFT UP AND OFF. NOTE: TURNING ON YOUR APPLIANCE WHEN IT HAS BEEN OFF FOR AWHILE MAY CAUSE CONDENSATION TO APPEAR ON THE GLASS.
  • Page 8: Lighting Instructions

    Page 8 Clarity 26 FS IPI LIGHTING INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand.
  • Page 9: 885 Proflame Valve

    Clarity 26 FS IPI Page 9 885 PROFLAME VALVE 885 PROFLAME VALVE ON-OFF solenoid EV1 terminals ON-OFF solenoid EV2 terminals Inlet pressure test point Outlet pressure test point Electrical pressure modulator device Pressure modulator device terminal Pilot adjusting screw Pilot outlet Gas inlet with protective seal Gas outlet with protective seal Ground connection...
  • Page 10: Operating Instructions

    Page 10 Clarity 26 FS IPI OPERATING INSTRUCTIONS PROFLAME 2 WALL MOUNT TRANSMITTER / REMOTE Intermittent Pilot Ignition (IPI) Only included and used for the CLARITY 26 FS IPI. The Profl ame 2 Transmitter is an integrated part of the Profl ame 2 System, which consists of these elements: A Profl...
  • Page 11 Clarity 26 FS IPI Page 11 180.OM.CL26.FS.IPI E v1.02 September 6, 2017...
  • Page 12 Page 12 Clarity 26 FS IPI Fan control The optional fan kit can be controlled with the Transmitter. The fan speed can be adjusted through six (6) speeds. To control the fan press the MODE key (Fig. 1) to index to the fan control icon (Fig. 15). Use UP/DOWN arrow keys to turn on, off...
  • Page 13 Clarity 26 FS IPI Page 13 180.OM.CL26.FS.IPI E v1.02 September 6, 2017...
  • Page 14: Battery Holder / Transmitter

    Page 14 Clarity 26 FS IPI OPERATING INSTRUCTIONS cont. BATTERY HOLDER / TRANSMITTER The battery holder / transmitter consists of three elements: Profl ame 2 Transmitter Profl ame 2 Battery Holder Profl ame 2 Integrated Fireplace Control (IFC) TECHNICAL DATA: Supply voltage 6.0V (four 1.5 V AA batteries) Ambient temperature ratings...
  • Page 15: Maintenance And Service

    Clarity 26 FS IPI Page 15 MAINTENANCE and SERVICE ROUTINE MAINTENANCE Regularly: • Clean and remove any lint accumulations or debris from the grills and combustion or convection air passage ways. • Keep the appliance area free from combustible materials, such as paper, wood, clothing, gasoline, fl...
  • Page 16: Door Glass Replacement

    Removal and replacement of the glass from the door must be done by a qualifi ed service technician. The glass must be purchased from a Blaze King dealer. No substitute materials are allowed. Fig.2 180.OM.CL26.FS.IPI E v1.02...
  • Page 17: Burner Removal

    Clarity 26 FS IPI Page 17 MAINTENANCE and SERVICE cont. BURNER REMOVAL 1. Turn off the appliance and allow it to cool down completely. 2. Remove the glass door and safety screen (see “GLASS DOOR REMOVAL” on previoius page and “SAFETY SCREEN REMOVAL” below) 3.
  • Page 18: Fuel Conversion

    Page 18 Clarity 26 FS IPI MAINTENANCE and SERVICE cont. THIS CONVERSION KIT SHALL BE INSTALLED BY A QUALIFIED SERVICE AGENCY IN ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS AND ALL APPLICABLE CODES AND REQUIREMENTS OF THE AUTHORITIES HAVING JURISDICTION. IF THE INFORMATION IN THESE INSTRUCTIONS IS NOT FOLLOWED EXACTLY, A FIRE, EXPLOSION OR PRODUCTION OF CARBON MONOXIDE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
  • Page 19 Clarity 26 FS IPI Page 19 MAINTENANCE and SERVICE cont. How to convert CLARITY 26 FS IPI Pilot fuel: 1. Remove the spring clamped hood from pilot and Fig.5 set aside (Fig. 5). 2. Unscrew regulator from pilot using a 4 mm allen key (Fig.
  • Page 20 Page 20 Clarity 26 FS IPI MAINTENANCE and SERVICE cont. 180.OM.CL26.FS.IPI E v1.02 September 6, 2017...
  • Page 21: Installation

    Clarity 26 FS IPI Page 21 INSTALLATION This section of the owner’s manual is for the use of qualifi ed service technicians only. Fireplace placement, hearths, and venting terminations will be covered, as well as the gas and electrical systems. Please read “SAFETY PRECAUTIONS” at the front of this manual.
  • Page 22 Page 22 Clarity 26 FS IPI INSTALLATION cont. 7. Loosen the top left tab as shown(Fig.5). NOTE: THE SIDE WITH LABEL SHOULD BE FACING FIREBOX, REMOVE BEFORE FIRING. Rest left side panel on the panel support, slide tab over panel, and retighten. HANDLE GLASS CAREFULLY BY THE EDGES, DO NOT LEAVE FINGERPRINTS, CLEAN IF NECESSARY.
  • Page 23: Precautions

    Clarity 26 FS IPI Page 23 INSTALLATION cont. PRECAUTIONS • The installation must conform to the installation codes. • This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate ventilation air. Provide adequate clearance around air openings of the appliance. Never obstruct front openings.
  • Page 24: Rear Vent Installation

    Page 24 Clarity 26 FS IPI INSTALLATION cont. REAR VENT INSTALLATION Two snorkels are available that can be used in a rear vent application on the CLARITY 26 FS. One is the M&G Duravent 46DVA-H2-SNK36 (Fig. 9), and the other is the Selkirk 4DT-ST36 (Fig. 10). Fig.9 Fig.10 CONVERSION TO REAR VENT...
  • Page 25 Clarity 26 FS IPI Page 25 INSTALLATION cont. 2. Remove screws from top rear grill assembly (1 screw each side of leg, two screws each side of fl ue collar). 3. Remove top rear grill assembly from appliance and set aside. 4.
  • Page 26 Page 26 Clarity 26 FS IPI INSTALLATION cont. 5. Rotate outer rear shield and place below such that the connected wires are not compromised. 6. Remove screws from fl ue collar (6 screws). 7. Rotate fl ue collar as shown and re-install to appliance (6 screws).
  • Page 27: Clearance To Combustibles

    Clarity 26 FS IPI Page 27 INSTALLATION cont. CLEARANCE TO COMBUSTIBLES Side of unit to sidewall 2” (51 mm) Back of unit to back wall 2.5” (64 mm) Corner of unit to sidewall 2” (51 mm) Top of unit to alcove ceiling 33”...
  • Page 28: Gas Connections

    Page 28 Clarity 26 FS IPI INSTALLATION cont. GAS CONNECTIONS Have your gas supplier or a qualifi ed gas fi tter run a gas supply line into the gas fi replace. The line must be properly sized and fi tted according to the installation codes. This unit is equipped with a manual shutoff...
  • Page 29 Clarity 26 FS IPI Page 29 INSTALLATION cont. A MINIMUM CLEARANCE OF 1” TO COMBUSTIBLES MUST BE MAINTAINED ON VERTICAL PIPE RUNS AND 2” FOR HORIZONTAL PIPE RUNS (SIDES AND BOTTOM 1”) The rigid vent systems use twist lock connections. The adaptor attached to the unit connects to the approved venting system.
  • Page 30: Vertical Vent Installation

    Page 30 Clarity 26 FS IPI INSTALLATION cont. VERTICAL VENT INSTALLATION Always maintain the 1” clearance around the vent pipe (vertical), when passing through ceilings, walls, roofs, enclosures, attic rafters or any combustible surfaces. DO NOT PACK AIR SPACES WITH INSULATION. Refer to the vent chart for maximum allowable vertical and horizontal installations.
  • Page 31: Venting

    Clarity 26 FS IPI Page 31 INSTALLATION INSTRUCTIONS cont. VENTING This appliance will not function without being connected to a proper venting system. This unit can be used with M&G Duravent, BDM, American Metal, Selkirk (Direct-Temp), Olympia, and ICC venting. Read the manufacturer’s installation instructions before installing the venting system.
  • Page 32: Vertical Venting

    Page 32 Clarity 26 FS IPI INSTALLATION INSTRUCTIONS cont. VERTICAL VENTING Example 1 V Value = 3A (12’) + 1C (3’) = 15’ H Value = 2B (4’) =4’ V Value = Total length of all vertical sections in feet. H Value = Total length of all horizontal sections in feet.
  • Page 33: Vent Termination Restrictions

    Clarity 26 FS IPI Page 33 INSTALLATION INSTRUCTIONS cont. VENT TERMINATION RESTRICTIONS Fig.13 VENT TERMINATION RESTRICTIONS, REFER TO Table 1 Table 1 VENT TERMINATION CLEARANCES 180.OM.CL26.FS.IPI E v1.02 September 6, 2017...
  • Page 34 Page 34 Clarity 26 FS IPI INSTALLATION INSTRUCTIONS cont. NOTE: • If an off set is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3’0” (914 mm), to avoid excessive stress on the elbows, and possible separation. Use wall straps as needed.
  • Page 35: Vent Restrictor

    Clarity 26 FS IPI Page 35 INSTALLATION INSTRUCTIONS cont. VENT RESTRICTOR Due to the extra fl ow produced by certain venting confi gurations the vent restrictor may be adjusted to maintain performance. If vent restriction is necessary it can be adjusted as follows: 1.
  • Page 36: Air Shutter Adjustment

    Page 36 Clarity 26 FS IPI INSTALLATION INSTRUCTIONS cont. AIR SHUTTER ADJUSTMENT The air shutter allows the amount of air coming into the fi replace to be adjusted in order to accommodate diff erent climates and venting arrangements. 1. To access the air shutter adjustment lever, open the hinged door beneath the fi...
  • Page 37: Mobile Home Installation

    CEILING/ROOF MUST BE MAINTAINED. Fig.18 ELECTRICAL REQUIREMENTS: For CLARITY 26.FS.IPI and Z5177.SP FAN KIT ELECTRICAL GROUNDING INSTRUCTIONS THIS APPLIANCE IS EQUIPPED WITH A THREE PRONG (GROUNDING) PLUG FOR YOUR PROTECTION AGAINST SHOCK HAZARD AND SHOULD BE PLUGGED DIRECTLY INTO A PROPERLY GROUNDED THREE PRONG RECEPTACLE .
  • Page 38 Page 38 Clarity 26 FS IPI INSTALLATION INSTRUCTIONS cont. CONFIGURATION FOR CLARITY 26 FS IPI 600.199.103 PF2 PILOT ASM 600.584.924 600.885.009 MAIN WIRE PF2 VALVE HARNESS 600.584.045 PROFLAME TRANSMITTER Z5177.IPI Z5177.SP OPTIONAL 600.584.922 BLOWER BATTERY HOLDER WIRE HARNESS 600.584.103 BATTERY HOLDER 180.OM.CL26.FS.IPI E v1.02 September 6, 2017...
  • Page 39: Optional Log Set

    Clarity 26 FS IPI Page 39 INSTALLATION INSTRUCTIONS cont. OPTIONAL LOG SET: ONLY THE LOG SET SUPPLIED BY THE MANUFACTURER MAY BE USED WITH THIS APPLIANCE. THE LOG SET MUST BE INSTALLED AS DESCRIBED IN THIS MANUAL. DANGEROUS OPERATING CONDITIONS MY OCCUR IF THESE LOGS ARE NOT POSITIONED IN THEIR APPROVED LOCATIONS.
  • Page 40 Page 40 Clarity 26 FS IPI INSTALLATION INSTRUCTIONS cont. 3. Place the center “V” shaped log onto the previous two logs as shown. (Fig.3) Fig.3 4. Position the front left log as shown. (Fig. 4) DO NOT IMPINGE FLAME WITH LOG, it should be just in front of the burner.
  • Page 41: Rigid Venting Parts List

    Clarity 26 FS IPI Page 41 RIGID VENTING PARTS LIST M&G DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST DESCRIPTION PART OLD PART 6” Pipe Length -Black 46DVA-06B 908B 6” Pipe Length –Galvanized 46DVA-06 8,5” Black Extension (3”-7”) 46DVA-08AB 8,5” Galvanized Extension (3”-7”) 46DVA-08A 9”...
  • Page 42 Page 42 Clarity 26 FS IPI BDM PARTS LIST PART DESCRIPTION 4" x 6 5/8" DIRECT VENT PIPE: 94610606 6'' GALVANIZED PRO FORM DV PIPE 94610606B 6'' GALVANIZED PRO FORM DV PIPE BLACK 94610609 9'' GALVANIZED PRO FORM DV PIPE 94610609B 9'' GALVANIZED PRO FORM DV PIPE BLACK 94610612...
  • Page 43 Clarity 26 FS IPI Page 43 BDM PARTS LIST cont. TYPE PART DESCRIPTION OTHER COMPONENTS Vertical Round Co-Axial Caps: 940264 4'' INSIDE 6 5/8'' ROUND VCA PRO FORM DV TERM CAP Ceiling Firestop: 94980612 4'' INSIDE 6 5/8'' PRO FORM DV CEILING FIRESTOP Attic Insulation Shield: 94930620A 4'' INSIDE 6 5/8''PRO FORM DV ATTIC INSULATION SHIELD (Adjustable)
  • Page 44 Page 44 Clarity 26 FS IPI SELKIRK PARTS LIST PRODUCT NUMBER PART DESCRIPTION 4" x 6 5/8" LENGTHS 1604006 4DT- 6 DIRECT-TEMP 6" PIPE LENGTH 1604006B 4DT- 6B DIRECT-TEMP 6" PIPE LENGTH BLACK 1604009 4DT- 9 DIRECT-TEMP 9" PIPE LENGTH 1604009B 4DT- 9B DIRECT-TEMP 9"...
  • Page 45 Clarity 26 FS IPI Page 45 SELKIRK PARTS LIST cont. PRODUCT NUMBER PART DESCRIPTION 4" x 6 5/8" SUPPORTS 1604400 4DT-CS CEILING SUPPORT 1604424 4DT-CCS CATHEDRAL SUPPORT BOX 1604430 4DT-WS/B WALL SUPPORT/BAND 1604435 4DT-OS OFFSET SUPPORT 4" x 6 5/8" TERMINATIONS AND FLASHINGS 1604620 4DT-VKC VERTICAL TERMINATION KIT...
  • Page 46 Page 46 Clarity 26 FS IPI OLYMPIA PARTS LIST PART DESCRIPTION PART DESCRIPTION VDV-0406 4" x 6" L Direct Vent Pipe VDVB-0424 4"x24"L Direct Vent Black Pipe VDV-0406-6 4" x 6" DV Pipe 6 Pack VDVB-0436 4"x36"L Direct Vent Black Pipe VDV-0406SL 4"...
  • Page 47 Clarity 26 FS IPI Page 47 ICC PARTS LIST 4" x 6 5/8" LENGTHS DESCRIPTION PART 6” Length - Galvalume TC-4DL6 6" Length - Black TC-4DL6B 9" Length - Galvalume TC-4DL9 9" Length - Black TC-4DL9B 12" Length - Galvalume TC-4DL1 12"...
  • Page 48: Valve Removal And Installation

    Page 48 Clarity 26 FS IPI VALVE REMOVAL AND INSTALLATION TO BE DONE BY QUALIFIED PERSONNEL ONLY 1. Disconnect the gas, see gas valve shutoff , and electricity to the appliance. 2. Remove fan if installed. 3. Remove the bottom and rear wire shields (7 screws, 1 ground). (Fig. 1) 4.
  • Page 49: Parts List

    Clarity 26 FS IPI Page 49 PARTS LIST ITEM PART ITEM PART DESCRIPTION DESCRIPTION NUMBER NUMBER Z5151 WINDOW LATCH ASSEMBLY 610.199.059 PF2 PILOT ASSEMBLY 5103 FIREBOX BAFFLE 645.1821 SAFETY SCREEN 21” X 18.5” 130.0501.L GLASS CERAM MIRROR LEFT Z5104 FLOOR PLATE RIVET ASSEMBLY 620.5101 CERAMIC PANEL REAR CLARITY 640.5101...
  • Page 50: Troubleshooting

    Page 50 Clarity 26 FS IPI TROUBLESHOOTING DIAGNOSTIC FLASH CODES ON IFC CONTROL 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2.
  • Page 51 Clarity 26 FS IPI Page 51 TROUBLESHOOTING cont. Please check to make sure the instructions are followed exactly before attempting trouble shooting of the appliance. TROUBLESHOOTING AND SERVICING OF GAS AND ELECTRICAL DEVICES OF THE APPLIANCE SHOULD ONLY BE CONDUCTED BY A QUALIFIED SERVICE TECHNICIAN PROBLEM POSSIBLE CAUSE ACTION...
  • Page 52 Page 52 Clarity 26 FS IPI TROUBLESHOOTING cont. • Turn the system off by pressing the ON/OFF button on the transmitter • After approximately 2 seconds press the ON/OFF button on the transmitter again. Locking conditions Reset the Profl ame IFC board •...
  • Page 53: Warranty

    Blaze King and its respective brands extend the following warranty for gas appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts.
  • Page 54 Blaze King is the manufacturer of the Blaze King line of heating products. At Blaze King, our commitment to the highest level of quality and customer service is the most important thing we do. Each Blaze King stove is built on a tradition of using only the fi...
  • Page 55 WARRANTY cont. If you are not satisfi ed with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
  • Page 56 Labor rates are set per component and as such total labor costs may not be covered. 26. If a defect or problem is determined by Blaze King to be non warrantable, Blaze King will not be liable for travel costs for service work.
