For use with natural gas (NG) or propane (LPG)
INSTALLATION
4011009
5007099
Date Installed: ____________
Serial No.: _____________
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
180-CL2118-SP v1.00
CLARITY CL2118.SP
DIRECT VENT GAS ROOM HEATER
with Standing Pilot (SP)
OPERATION &
MANUAL
WARNING:
instructions are not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
If the information in these
May 22, 2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blaze King Clarity CL2118 SP
Summary of Contents for Blaze King Clarity CL2118 SP
- Page 1 CLARITY CL2118.SP DIRECT VENT GAS ROOM HEATER with Standing Pilot (SP) For use with natural gas (NG) or propane (LPG) WARNING: If the information in these OPERATION & instructions are not followed exactly, a fi re INSTALLATION or explosion may result causing property MANUAL damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Page 2 Clarity CL2118 SP TABLE OF CONTENTS SAFETY PRECAUTIONS _________________________________________________________________ 4 GENERAL ..................................4 YOUR SAFETY ................................5 INSTALLATION ................................5 GENERAL INFORMATION ________________________________________________________________ 6 APPLIANCE CERTIFICATION ..........................6 INSTALLATION CODES ............................6 SPECIFICATIONS..............................6 HIGH ALTITUDE INSTALLATION ........................6 CERTIFICATION LABEL __________________________________________________________________ 7 DIMENSIONS _____________________________________________________________________________ 8 CLEARANCE TO COMBUSTIBLES ........................8... - Page 3 Clarity CL2118 SP Page 3 SAFETY PRECAUTIONS VENT TERMINATION RESTRICTIONS ......................35 VENT RESTRICTOR ...............................37 AIR SHUTTER ADJUSTMENT ..........................38 BURNER FLAME APPEARANCE ........................38 MOBILE HOME INSTALLATION ..........................39 ELECTRICAL REQUIREMENTS: ........................39 RIGID VENTING PARTS LIST _____________________________________________________________ 42 VALVE REMOVAL & INSTALLATION _____________________________________________________ 49...
-
Page 4: Safety Precautions
Page 4 Clarity CL2118 SP SAFETY PRECAUTIONS This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes. FIRE OR EXPLOSION HAZARD This appliance is only for use with the type of gas Failure to follow safety warnings indicated on the rating plate. -
Page 5: Your Safety
Clarity CL2118 SP Page 5 SAFETY PRECAUTIONS YOUR SAFETY • Have the venting system inspected annually by a qualifi ed installer for blockage and signs of deterioration. • To prevent injury, do not allow anyone who is unfamiliar with the stove to operate it. -
Page 6: General Information
Page 6 Clarity CL2118 SP GENERAL INFORMATION APPLIANCE CERTIFICATION This appliance is tested and certifi ed to the following US and Canadian gas appliance standards: • ANSI Z21.88-2016 / CSA 2.33b-2016 Vented Gas Fireplace Heaters, • CAN/CGA-2.17-M91 (R2014) Gas-Fired Appliance for Use at High Altitudes •... -
Page 7: Certification Label
MANUFACTURE DATE MANUFACTURED IN: JAN FEB MAR APR MAY JUN USA: Blaze King Industries CANADA: Valley Comfort Systems JUL AUG SEP OCT NOV DEC 146A Street, Walla Walla, WA. 99362 1290 Commercial Way, Penticton, B.C. -
Page 8: Dimensions
Page 8 Clarity CL2118 SP DIMENSIONS NOTE: TURNING ON YOUR APPLIANCE WHEN IT HAS BEEN OFF FOR AWHILE MAY CAUSE CONDENSATION TO APPEAR ON THE GLASS. THIS IS A NORMAL OCCURRENCE AS YOUR APPLIANCE HEATS UP. CLEARANCE TO COMBUSTIBLES Side of unit to sidewall 4”... -
Page 9: Lighting Instructions
Clarity CL2118 SP Page 9 LIGHTING INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. This appliance has a pilot which is lit with a push button piezo lighter. When lighting the pilot, follow these instructions exactly. -
Page 10: 820 Nova Valve
Page 10 Clarity CL2118 SP 820 NOVA VALVE 15 6 820 NOVA VALVE ON/PILOT/OFF Knob Manual HI-LO adjustment or pressure regulator adjustment Pilot adjustment Thermocouple connection Mounting for piezo & bracket Inlet pressure test point Outlet pressure test point Main operator... -
Page 11: Operating Instructions
(Fig.1). LIGHTING THE BURNER Fig.1 Standing Pilot (SP) The CLARITY CL2118 SP controls are located behind the hinged fl ap beneath the fi rebox.(Fig.2) To light the burner follow the steps below: Make sure the pilot is lit (see “LIGHTING INSTRUCTIONS Standing Pilot”) -
Page 12: Maintenance And Service
Page 12 Clarity CL2118 SP MAINTENANCE and SERVICE ROUTINE MAINTENANCE Regularly: • Clean and remove any lint accumulations or debris from the grills and combustion or convection air passage ways. • Keep the appliance area free from combustible materials, such as paper, wood, clothing, gasoline, fl... -
Page 13: Glass Door Removal
Clarity CL2118 SP Page 13 MAINTENANCE and SERVICE GLASS DOOR REMOVAL For installation, cleaning, and burner removal the glass door must be removed. 1. Turn off the appliance and allow it to cool down completely. 2. Lift the face trim up and out, away from the appliance, and set it aside.(Fig.4) -
Page 14: Glass Door Replacement
Removal and replacement of the glass from the door must be done by a qualifi ed service technician. The glass door must be purchased from a Blaze King dealer. No substitute materials are allowed. Fig.7 BURNER REMOVAL 1. -
Page 15: Safety Screen Replacement
Clarity CL2118 SP Page 15 MAINTENANCE and SERVICE SAFETY SCREEN REPLACEMENT The CLARITY CL2118 is supplied with a safety screen pre-installed inside the door trim. If the safety screen becomes damaged it must be replaced with part #645.1821 1. Turn off the appliance and allow it to cool down completely. -
Page 16: Fuel Conversion
4. Convert pilot fuel (see below) 5. Replace regulator (see next page) How to convert CLARITY CL2118 SP Pilot orifi ce: 1. Use a 7/16” wrench to loosen the pilot hood. 2. Push the little tab in and the little tab with hole should pop out. The hole stamp tab (LP) out is used for Propane. - Page 17 Clarity CL2118 SP Page 17 MAINTENANCE and SERVICE installationinstructions 820 NOVA HI/LO Conversion Kit WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. This installation or replacement instruction refer to HI-LO pressure regulator kit to be used to convert the 820 Nova Combination Gas Control with adjustable pressure regulator into manual HI-LO.
-
Page 18: Installation Planning
Page 18 Clarity CL2118 SP INSTALLATION PLANNING This section of the owner’s manual is for the use of qualifi ed service technicians only. Fireplace placement, hearths, and venting terminations will be covered, as well as the gas and electrical systems. Please read “SAFETY PRECAUTIONS”... -
Page 19: Framing - Corner Installtion
Clarity CL2118 SP Page 19 INSTALLATION PLANNING FRAMING - CORNER INSTALLTION The dimensions for installing the CL2118 appliance in a corner is shown in Fig.12. Do not interfere with the structural integrity of the walls. Shown below are minimum clearances; increasing these dimensions is allowable as long as vent length remains in the allowable range. -
Page 20: Wall Finish
Page 20 Clarity CL2118 SP INSTALLATION PLANNING WALL FINISH Non-combustible cement board. The CL2118 appliance requires a 1/2” (13 mm) thick non-combustible cement board to be used as a wall surface immediately surrounding the unit on each side (see Fig13. below) for minimum coverage. -
Page 21: Cracking Wall Finishes
Clarity CL2118 SP Page 21 INSTALLATION PLANNING CRACKING WALL FINISHES If a clean fi nish with no tile, etc. is desired, joints in the cement board and the transition to gypsum board will require special attention if future cracking is to be controlled. Be aware that temperatures on the noncombustible wall surface above the appliance can exceed 250°F. -
Page 22: Installation
HARDWIRING FOR OPTIONAL BLOWER There are electrical access panels on either side of the Clarity CL2118 SP for hardwiring power, install per local electrical building codes . Follow the steps below for running a hardwire power line to the Clarity CL2118 SP: 1. -
Page 23: Optional Blower Installation For Existing Cl2118 Installation
Clarity CL2118 SP Page 23 INSTALLATION OPTIONAL BLOWER INSTALLATION FOR 3. Coil the wires inside the junction box and refasten EXISTING CL2118 INSTALLATION the cover plate. 1. If attached, unscrew junction box coverplate from inside. (2 screws) 2. Run the black and white wires from the blower through the end strain relief of the junction box. -
Page 24: Initial Setup
Page 24 Clarity CL2118 SP INSTALLATION INITIAL SETUP 1. Remove the safety screen, and door glass as shown in “GLASS DOOR REMOVAL”, set assemblies aside. 2. REMOVE THE STATIC CLING LABEL THAT IS ON THE DOOR GLASS. Hold glass to frame when removing as it is only held in place with silicone. -
Page 25: Vent Termination Location
Clarity CL2118 SP Page 25 INSTALLATION 9. If installing the optional log set (Fig.17) refer to installation instructions supplied with log set, if not continue below. 10. Repeat “GLASS DOOR REMOVAL” steps in reverse order to complete initial setup. Fig.17 VENT TERMINATION LOCATION •... -
Page 26: Rear Vent Installation
Page 26 Clarity CL2118 SP INSTALLATION REAR VENT INSTALLATION Two snorkels are available that can be used in a rear vent application on the CLARITY CL2118. One is the M&G Duravent 46DVA-H2-SNK36 (Fig.18), and the other is the Selkirk 4DT-ST36 (Fig.19). - Page 27 Clarity CL2118 SP Page 27 INSTALLATION 2. Remove upper fl ue access cover from the appliance and set aside. (Fig.21) Fig.21 3. Remove the lower fl ue access cover from appliance and set aside. (Fig.22) Fig.22 4. Unscrew fl ue collar from appliance. (6 screws) (Fig.23) Ensure that the sealing gasket is not...
- Page 28 Page 28 Clarity CL2118 SP INSTALLATION 5. Rotate fl ue collar as shown and re-install to appliance (6 screws). Ensure gasket is seated properly. (Fig.24) 6. Re-install the fl ue access covers, discard the back sheild. Fig.24 180-CL2118-SP v1.00 May 22, 2018...
-
Page 29: Gas Connections
Clarity CL2118 SP Page 29 INSTALLATION GAS CONNECTIONS Have your gas supplier or a qualifi ed gas fi tter run a gas supply line to the gas fi replace. The line must be properly sized and fi tted according to the installation codes with a manual shutoff ball valve. The inlet has a 3/8”... - Page 30 Page 30 Clarity CL2118 SP INSTALLATION ON VERTICAL PIPE RUNS A MINIMUM VENT CLEARANCE OF 1” (26 mm) TO COMBUSTIBLES MUST BE MAINTAINED ON HORIZONTAL PIPE RUNS A MINIMUM VENT CLEARANCE OF 13” (330 mm) ABOVE, 2 1/2” (64 mm) ON SIDES, AND 1” (26 mm) BELOW, MUST BE MAINTAINED The rigid vent systems use twist lock connections.
-
Page 31: Venting
Clarity CL2118 SP Page 31 INSTALLATION VENTING This appliance will not function without being connected to a proper venting system. This unit is certifi ed for use with M&G Duravent, BDM, American Metal, Selkirk (Direct-Temp), Olympia, and ICC venting. Read the manufacturer’s installation instructions before installing the venting system. -
Page 32: Typical Venting Examples
Page 32 Clarity CL2118 SP INSTALLATION TYPICAL VENTING EXAMPLES 12" 12" TOP VENT VERTICAL 2’0” UP AND OUT 12" REAR VENT WITH SNORKLE 180-CL2118-SP v1.00 May 22, 2018... -
Page 33: Vertical Vent Installation
Clarity CL2118 SP Page 33 INSTALLATION VERTICAL VENT INSTALLATION Always maintain the 1” clearance around the vent pipe (vertical), when passing through ceilings, walls, roofs, enclosures, attic rafters or any combustible surfaces. DO NOT PACK AIR SPACES WITH INSULATION. Refer to the vent chart for maximum allowable vertical and horizontal installations. - Page 34 Page 34 Clarity CL2118 SP INSTALLATION VERTICAL VENTING Example 1 V Value = 3A (12’) + 1C (3’) = 15’ H Value = 2B (4’) =4’ V Value = Total length of all vertical sections in feet. H Value = Total length of all horizontal sections in feet.
-
Page 35: Vent Termination Restrictions
Clarity CL2118 SP Page 35 INSTALLATION VENT TERMINATION RESTRICTIONS Fig.11 VENT TERMINATION RESTRICTIONS, REFER TO Table 1 Table 1 VENT TERMINATION CLEARANCES 180-CL2118-SP v1.00 May 22, 2018... - Page 36 Page 36 Clarity CL2118 SP INSTALLATION NOTE: • If an off set is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3’0” (914 mm), to avoid excessive stress on the elbows, and possible separation. Use wall straps as needed.
-
Page 37: Vent Restrictor
Clarity CL2118 SP Page 37 INSTALLATION VENT RESTRICTOR Due to the high draft produced by certain venting confi gurations the vent restrictor may be adjusted to maintain performance. If vent restriction is necessary it can be adjusted as follows: 1. Turn off the appliance and allow it to cool down completely. -
Page 38: Air Shutter Adjustment
Page 38 Clarity CL2118 SP INSTALLATION AIR SHUTTER ADJUSTMENT The air shutter allows the amount of air coming into the burner to be adjusted in order to accommodate diff erent climates and venting arrangements. 1. Remove the face trim to access the air shutter adjustment lever, it is in the lower left-hand side. -
Page 39: Mobile Home Installation
Clarity CL2118 SP Page 39 INSTALLATION MOBILE HOME INSTALLATION The CLARITY CL2118 can be installed in a mobile home but must be securely fastened to the fl oor. Use the provided mounting holes to secure the appliance to the framining.(Fig.31) Ensure the unit is electrically grounded permanently to the chassis of the home. - Page 40 Page 40 Clarity CL2118 SP INSTALLATION WIRING DIAGRAM Pilot assb 610.0712 on/off switch 145.0725 600.0842.VC 600.0721.A thermocouple thermopile pilot line 600.820.644 SIT Nova valve WIRING DIAGRAM OF OPTIONAL THERMOSTAT OR WALL SWITCH 70 ° F DOWN COOL / HEAT PROGRAM 180-CL2118-SP v1.00...
- Page 41 Clarity CL2118 SP Page 41 INSTALLATION CONFIGURATION FOR S.Z5216.SP CLARITY CL2118 SP FAN WIRING 24” wht 5” blk 180-CL2118-SP v1.00 May 22, 2018...
-
Page 42: Rigid Venting Parts List
Page 42 Clarity CL2118 SP RIGID VENTING PARTS LIST M&G DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST DESCRIPTION PART OLD PART 6” Pipe Length -Black 46DVA-06B 908B 6” Pipe Length –Galvanized 46DVA-06 8,5” Black Extension (3”-7”) 46DVA-08AB 8,5” Galvanized Extension (3”-7”) 46DVA-08A 9”... - Page 43 Clarity CL2118 SP Page 43 BDM PARTS LIST PART DESCRIPTION 4" x 6 5/8" DIRECT VENT PIPE: 94610606 6'' GALVANIZED PRO FORM DV PIPE 94610606B 6'' GALVANIZED PRO FORM DV PIPE BLACK 94610609 9'' GALVANIZED PRO FORM DV PIPE 94610609B...
- Page 44 Page 44 Clarity CL2118 SP BDM PARTS LIST cont. TYPE PART DESCRIPTION OTHER COMPONENTS Vertical Round Co-Axial Caps: 940264 4'' INSIDE 6 5/8'' ROUND VCA PRO FORM DV TERM CAP Ceiling Firestop: 94980612 4'' INSIDE 6 5/8'' PRO FORM DV CEILING FIRESTOP...
- Page 45 Clarity CL2118 SP Page 45 SELKIRK PARTS LIST PRODUCT NUMBER PART DESCRIPTION 4" x 6 5/8" LENGTHS 1604006 4DT- 6 DIRECT-TEMP 6" PIPE LENGTH 1604006B 4DT- 6B DIRECT-TEMP 6" PIPE LENGTH BLACK 1604009 4DT- 9 DIRECT-TEMP 9" PIPE LENGTH 1604009B 4DT- 9B DIRECT-TEMP 9"...
- Page 46 Page 46 Clarity CL2118 SP SELKIRK PARTS LIST cont. PRODUCT NUMBER PART DESCRIPTION 4" x 6 5/8" SUPPORTS 1604400 4DT-CS CEILING SUPPORT 1604424 4DT-CCS CATHEDRAL SUPPORT BOX 1604430 4DT-WS/B WALL SUPPORT/BAND 1604435 4DT-OS OFFSET SUPPORT 4" x 6 5/8" TERMINATIONS AND FLASHINGS...
- Page 47 Clarity CL2118 SP Page 47 OLYMPIA PARTS LIST PART DESCRIPTION PART DESCRIPTION VDV-0406 4" x 6" L Direct Vent Pipe VDVB-0424 4"x24"L Direct Vent Black Pipe VDV-0406-6 4" x 6" DV Pipe 6 Pack VDVB-0436 4"x36"L Direct Vent Black Pipe VDV-0406SL 4"...
- Page 48 Page 48 Clarity CL2118 SP ICC PARTS LIST 4" x 6 5/8" LENGTHS DESCRIPTION PART 6” Length - Galvalume TC-4DL6 6" Length - Black TC-4DL6B 9" Length - Galvalume TC-4DL9 9" Length - Black TC-4DL9B 12" Length - Galvalume TC-4DL1 12"...
-
Page 49: Valve Removal & Installation
Clarity CL2118 SP Page 49 VALVE REMOVAL & INSTALLATION TO BE DONE BY QUALIFIED PERSONNEL ONLY 1. Turn off the gas valve, disconnect the gas and electricity to the appliance. 2. Remove the face trim, safety screen, and glass door as shown in “GLASS DOOR REMOVAL”... -
Page 50: Parts List
Page 50 Clarity CL2118 SP PARTS LIST ITEM PART ITEM PART DESCRIPTION DESCRIPTION NUMBER NUMBER Z5151 WINDOW LATCH ASSEMBLY 610.0712 PILOT ASM ADJ NG_LPG PSE 5103 FIREBOX BAFFLE 600.SIT.013 EXTENSION KNOB HI LO 1.5” 130.0501.L GLASS CERAM MIRROR LEFT 600.SIT.012 EXTENSION KNOB ON/OFF 1.5”... -
Page 51: Troubleshooting
Clarity CL2118 SP Page 51 TROUBLESHOOTING Please check to make sure the instructions are followed exactly before attempting trouble shooting of the appliance. TROUBLESHOOTING AND SERVICING OF GAS AND ELECTRICAL DEVICES OF THE APPLIANCE SHOULD ONLY BE CONDUCTED BY A QUALIFIED SERVICE TECHNICIAN... -
Page 52: Warranty
Blaze King and its respective brands extend the following warranty for gas appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts. - Page 53 If you are not satisfi ed with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
- Page 54 18. The paint on the brick liner may peel. It is not a fl aw and is not covered under warranty, due to extreme conditions in the fi rebox. 19. Blaze King is free of liability for any damages caused by the fi replace or stove, as well as inconvenience expenses and materials. The Limited Warranty does not cover incidental or consequential damages.
- Page 55 Labor rates are set per component and as such total labor costs may not be covered. 26. If a defect or problem is determined by Blaze King to be non warrantable, Blaze King will not be liable for travel costs for service work.
-
Page 56: Notes
Page 56 Clarity CL2118 SP NOTES 180-CL2118-SP v1.00 May 22, 2018...
