Pyromaster Electric Fireplace HEF33
Bay Window Removal
NOTE: Applicable only to units with bay window.
1. Turn OFF electrical supply to unit.
2. Let fireplace cool down if it has been operating.
3. Remove top cover. (See Louvre Removal").
4. Open lower louvre assembly.
5. Remove two (2) retention screws along lower side
edges of bay window.
6. Swing lower portion of bay window out from
fireplace, and gently lift up to disengage top of bay
window from fireplace.
7. To reinstall the bay window, reverse the above
procedure.
Bay Window Information
NOTE: Applicable only to units with bay window.
1. Under no circumstances should this product be
operated with missing screen bay window.
2. Do not strike or slam the screen bay window.
3. This product uses screen bay window. Replace-
ment of the screen bay window as supplied by the
manufacturer should be done by a qualified
service person.
Maintenance of Motors
The motors used on the fan and the drum assembly
are prelubricated for extended bearing life and require
no further lubrication. However, periodic cleaning/
vacuuming of the fan/heater is recommended.
Make sure that the power is turned off
before proceeding.
Cleaning Brass Trim
Clean the brass trim using a soft cloth, slightly damp-
ened with lemon oil and buff with a clean soft cloth.
Do NOT use brass polish or household cleaners as
these products will damage the brass trim. Lemon oil
can be obtained at supermarkets or hardware stores.
8
10005721
