Grizzly Electric Motor G2909 Instruction Sheet

Model G2909 Specifications
Power .......................................................... 2 HP
Cycle ............................................................60Hz
Voltage .................................................110/220V
Prewired ......................................................220V
Amps ........................................................26/13A
RPM ............................................................. 3450
Phase ........................................................ Single
Class ..................................................................E
Start Capacitor ........................ 400MFD 125VAC
Dimensions .............................. 1
Replaceable Parts
REF PART # DESCRIPTION
1 P2909001 S CAPACITOR COVER
2 PC400H S CAPACITOR 400M 125V 1-7/8 X 3-1/2
3 P2909003 JUNCTION BOX
WARNING: NO PORTION OF THIS INSTRUCTION SHEET MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ "D x 3½"L
7
8
Disconnect power when
replacing motor. Failure
to do this may result in
serious personal injury.
COPYRIGHT © DECEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JB10221 PRINTED IN TAIWAN
MODEL G2909
2 HP ELECTRIC MOTOR
INSTRUCTION SHEET
Electrical Safety
If you are unsure how to attach wires to terminals,
DO NOT continue. Contact a qualified electrician
for assistance. Connecting wires improperly may
cause them to come loose or contact other wires,
which can cause electrocution, fire, or a short.
�
�
�
REF PART #
4 P2909004
5 P2909005
Electrocution or fire could
result if this motor is not
grounded correctly or if
your wire connections do
not comply with local and
state codes. Ensure com-
pliance by checking with a
qualified electrician!
�
�
DESCRIPTION
CENTRIFUGAL SWITCH
CONTACT PLATE
