Grizzly H5380 Instruction Sheet

Model H5380 Specifications
Power .......................................................... 1 HP
Cycle ............................................................60Hz
Voltage .................................................110/220V
Prewired ......................................................110V
Amps ....................................................12.6/6.3A
RPM ............................................................. 3450
Phase ........................................................ Single
Class ..................................................................B
Start Capacitor ........................ 300MFD 125VAC
Dimensions .............................. 1
Replaceable Parts
REF PART # DESCRIPTION
1 PH5380001 MOTOR FAN COVER
2 PH5380002 MOTOR FAN
3 PH5380003 S CAPACITOR COVER
4 PC300F S CAPACITOR 300M 125V 1-7/8 X 3-3/8
WARNING: NO PORTION OF THIS INSTRUCTION SHEET MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ "D x 3
7
8
Disconnect power when
replacing motor. Failure
to do this may result in
serious personal injury.
COPYRIGHT © DECEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JB10239 PRINTED IN TAIWAN
MODEL H5380
1 HP ELECTRIC MOTOR
INSTRUCTION SHEET
Electrical Safety
If you are unsure how to attach wires to terminals,
DO NOT continue. Contact a qualified electrician
for assistance. Connecting wires improperly may
cause them to come loose or contact other wires,
which can cause electrocution, fire, or a short.
⁄ "L
3
8
�
�
�
�
REF PART #
5 PH5380005
6 PH5380006
7 PH5380007
Electrocution or fire could
result if this motor is not
grounded correctly or if
your wire connections do
not comply with local and
state codes. Ensure com-
pliance by checking with a
qualified electrician!
�
�
�
DESCRIPTION
JUNCTION BOX
CENTRIFUGAL SWITCH
CONTACT PLATE
