B N S A S
ASIC ETWORK ETTINGS DVANCED ETTINGS
Fragment Threshold Enter the maximum size of a packet during data
transmission. A value too low could lead to low performance.
RTS Threshold Enter the RTS threshold. If the packet size is smaller than the
RTS threshold, the ERB300H/ERB150H does not use RTS/CTS to send the data
packet.
Beacon Interval Enter the beacon interval. This is the amount of time that the
ERB300H/ERB150H sets to synchronize the network.
Delivery Traffic Indication Message (DTIM) Period Enter the DTIM period. The
DTIM is a countdown period informing clients of the next point of broadcast and
multicast of messages over the network. Valid values are between 1 and 255.
N Data Rate Select the N data rate. This is the rate in which the ERB300H/
ERB150H will transmit data packets to wireless N compatible devices.
Channel Bandwidth Select the channel bandwidth. The factory default is Auto
20/40MHz. The default setting provides the best performance by auto selecting
channel bandwidth.
Preamble Type Select the preamble type. Long Preamble provides better LAN
compatibility and Short Preamble provides better wireless performance.
CTS Protection Select the type of CTS protection. Using CTS Protection can
lower the data collisions between Wireless B and Wireless G devices and lower
data throughput.
Tx Power Select the wireless signal strength level. Valid values are between 25%
and 100%.
Click Apply to save the settings or Cancel to discard changes.
6-21
