Front Panel

USER INTERFACE

FRONT PANEL
1
1 Power Switch: this turns VoicePrism On/Off as indicated by front panel illumination. When turned
2
2
Tab Arrows: these scroll forward or back one menu page or preset. You'll find them especially
3
3 Softknobs: the softknob names and current settings are displayed on the LCD; they will
4 LCD Display: the most informative part of VoicePrism, at the highest level this shows preset
4
5 Numeric Display: displays the current preset number. A "delta dot" in the bottom right corner
5
6 Input Indicators: these light up for the following input types.
6
7 Input Level LED Bar: the LED's illuminate to indicate the input volume level, from -30dB to
7
8
8
Edit Buttons: these 5 buttons jump you directly to your multi-page edit menus. Each button
Off, the VoicePrism is not completely disconnected from the mains. VoicePrism starts up with your
last settings and preset.
useful for navigating the multi-page menus.
change depending on your menu. Turning the softknobs will modify their settings. Pushing
the softknob until it clicks will access the softknob submenu (if available). In the softknob
submenu, twisting the associated softknob will scroll you through the list of parameters --
clicking again selects the highlighted parameter and kicks you out of the submenu. In the
top level preset window, clicking the softknobs brings up a shortcut menu of factory preset
configurations.
information in addition to the softknob libraries and controls. Elsewhere, the LCD provides
menus where you can view your editable features, particularly the softknob menus (by click-
ing the softknobs) and the softknob settings.
shows that the preset or step sequence has been changed but not saved.
: illuminates to indicate pitch tracking.
LOCK
: lights up when MIDI messages are received.
MIDI
44.1
: digital input received at 44.1kHz, for use with the upgrade card.
48
: digital input received at 48kHz for use with the upgrade card.
0dB. The red Ovf LED illuminates to indicate the level is too high and is being digitally clipped.
has its own section later in the manual that describes its menu screens and adjustable
parameters, thus only a very brief description is given here.
: accesses the editing screens for vocals.
VOCALS
: accesses the editing screens for the two separate post effects blocks.
EFFECTS
6
