AUDIO

FOOTSWITCH

The menu allows you to set the following overall audio processing parameters:
AUDIO
(Min, 1-9, Max): this raises and lowers the frequency threshold at
ESS SENSITIVITY
which an "ess" sound is passed dry or harmonized. At high settings, "ess" sounds
will be pitch shifted, potentially causing a grainy "ess" sound but also yielding supe-
rior pitch tracking. At low settings, your "ess'es" will sound natural, but at the risk of
tracking errors on some voices.
have experience tracking errors.
- (0 - 100%): tweak this setting to silence unwanted sibilants, especially
ANTI FEEDBACK
from vocals. It works by lowering the level of the high frequencies that initially create
the "sss" sound.
(0% - 100%): reduces the effect of low frequency leakage into the
BASS REJECT
microphone. Tweak this if your bass player is a little to loud and causing weird trig-
gering effects.
(440H ) (-64c - +63c): sets the offset from the tuning frequency of 440Hz, or
TUNING Z
the "A" note just above middle "C" ("C", for those of you wondering, is 261.63Hz).
Use this to change VoicePrism's 440Hz reference to match a piano that has shifted
pitch but is still in tune relative to itself. This feature is also helpful when working
with tracks recorded using guitars tuned by ear, rather than by machine, allowing
you to match the guitar's more liberal interpretation of the reference A note.
You can configure the buttons for a one or three button footswitch by twisting the
softknob under the button description. VoicePrism is factory configured for a one
button footswitch, the Right button which is initially set to
Middle buttons are set to
three button footswitch, you can set useful functions to the Left and Middle buttons;
if you go back to a one button footswitch, remember to set the Left and Middle but-
tons back to . Warning: if the Left and Middle buttons are not set to
NONE
one button footswitch, pressing the footswitch button will cause VoicePrism to
behave unpredictably.
A more detailed description of each setting is shown on the LCD. Configuration
choices are:
: pressing the footswitch button does nothing. For a one button footswitch the
NONE
Middle and Left buttons must be set to
: Harmony Mute (Momentary) - activates the harmony voices only while
MUTE MO
the button is pressed.
: Harmony Mute (Latched) - mutes the harmonies until the button is
MUTE LC
pressed again.
: Bypass (Momentary) - bypasses VoicePrism while the button is pressed.
BYP MO
: Bypassed (Latched) - bypasses VoicePrism until the button is pressed again.
BYP LC
+ : Next Song Step - increments to the next preset defined within a song.
SONG
- : Previous Song Step - decrements to the previous preset defined within a
SONG
song
+ : Next Preset - increments numerically to the next preset (Preset 25 to
PRESET
Preset 26)
- : Previous Preset - decrements numerically to the previous preset (Preset 26
PRESET
to Preset 25)
is best left at
ESS SENSITIVITY
. If you change from a single button footswitch to a
NONE
.
NONE
27
Utility: Audio, Footswitch
(default) unless you
5
and the Left and
MUT MO
with a
NONE
