APPENDIX E: TECHNICAL SPECIFICATIONS

Digital Output
Connector:
Format:
Sample Rates:
Frequency Response @ Digital Out:
Analog Inputs
Connectors:
Impedance (Bal/Unbalanced - Line):
Max. Input Level Line:
A to D Conversion:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
Analog Outputs
Connectors:
Impedance:
Max. Output Level:
D to A Conversion:
Analog Through
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
EMC
Safety
Environment
Control Interface
Power
Mains Voltage:
Power Consumption:
Fuses:
General
Finish:
Display:
Dimensions:
Weight:
Warranty Parts and Labour:
RCA Phono (S/PDIF)
24 bit
44.1kHz
20Hz - 20kHz
XLR Balanced (pin 2 hot), TRS 1/4"
28 kOhms
+21dBu
24 bits, 100dB dynamic range (A-weighted), 44.1kHz sampling rate.
-100dB (A-weighted)
0.0026% @ 1kHz (A-weighted)
10Hz - 12kHz ±0.8dB, -2dB @ 20kHz
-105dB @ 1kHz
TRS 1/4"
60 Ohms
+21 dBu
24 bits, 100dB dynamic range (A-weighted), 44.1kHz sampling rate
-100dB (A-weighted)
0.007% @ 1kHz
10Hz - 12kHz ±0.8dB, -2dB @ 20kHz
-105dB @ 1kHz
Complies with: EN 55103 1/2, ENS 5022 Class B, EN61000-4-2/3/4/5/6/11
Certified to: EN 60065, CAN/CSA E60065-00, UL 6500
Max. Operating Temperature: 50 degree Celsius (122 degrees Fahrenheit)
Min. Storage Temperature: -25 degrees Celsius (-13 degrees Fahrenheit)
MIDI: In/Out/Thru: 5 Pin DIN
GPI, Pedal: 1/4" Stereo Jack
100 to 240 VAC, 50 to 60 Hz
40W
250V 500mA Slow Blow (North America and Japan)
250V 500mA Time Lag (Europe and United Kingdom)
Powdercoat Electro Galvanized Steel, ABS Plastic Bezel, Knobs and Buttons.
128 x 64 Graphics LCD
19" x 3.5" x 8.2" (483mm x 89mm x 208mm)
7.8 lb (3.54kg)
1 year
E-1
Technical Specifications
