Page 1 Dynamic Cooking Systems, Inc. THE PROFESSIONAL DS, FS SERIES GRILL Use and Care Guide Models: ■ DCS27FS-BQ ■ DCS27FS-BQR ■ DCS36DS-BQAR ■ DCS36DS-BQR ■ DCS36DS-BQA ■ DCS48DS-BQAR ■ DCS48DS-BQR ■ DCS48DS-BQA...
Page 2 A Message T o Ou r Custome rs Thank you for selecting this DCS Professional “DS & FS” Series Grills. Because of these appliances unique features we have developed this Use and Care Guide. It contains valuable information on how to properly operate and maintain your new appliance for years of safe and enjoyable cooking.
Page 3: Table Of Contents
T able Of Contents SAFETY PRACTICES & PRECAUTIONS ................3-4 GRILL MODELS ............................5 GAS REQUIREMENTS ........................6-7 LOCATING GRILL / BUILT-IN CLEARANCES ..............8-9 BUILT-IN CONSTRUCTION DETAILS ................10-11 LEAK TESTING .............................12 INSTALLER FINAL CHECKLIST ....................13 BURNER ADJUSTMENTS ......................13-14 USING THE GRILL ........................14-16 LIGHTING INSTRUCTIONS ....................16-17 USING THE SMOKER SYSTEM ....................18...
Page 4: Safety Practices & Precautions
Safety Practices & Precautions IMPORTANT SAFETY NOTICE: Certain Liquid Propane dealers may fill liquid propane cylinders for use in the grill beyond cylinder filling capacity. This “Overfilling” may create a dangerous condition. “Overfilled” tanks can build up excess pressure. As a safety device, the tanks pressure relief valve will vent propane gas vapor to relieve this excess pressure.
Page 5 Safety Practices & Precautions For personal safety, wear proper apparel. Loose fitting garments or sleeves should never be worn while using this appliance. Some synthetic fabrics are highly flammable and should not be worn while cooking. Only certain types of glass, heat-proof glass ceramic, earthenware, or other glazed utensils are suitable for grill use.
Page 6: Grill Models
Grill Models DCS48DS-BQAR DCS48DS-BQR DCS48DS-BQA DCS48DS-BQ DCS36DS-BQAR DCS36DS-BQR DCS36DS-BQA DCS27FS-BQ DCS27FS-BQR...
Page 7: Gas Requirements
Gas Requi rements Verify the type of gas supply to be used, either FIG.01 Natural Gas (36BQR Shown) natural or L.P., and make sure the marking on the appliance rating plate agrees with that of the supply. The rating plate is located on the inside back wall of the Grill.
Page 8: Gas Requirements
Gas Requi rements the grill inlet pipe to avoid shifting any internal gas lines of the grill. Ensure that the regulator arrow points in the direction of gas flow towards the unit, away from the supply. Do not forget to place the installer supplied gas valve in an accessible location.
Page 9: Locating Grill/Built-In Clea Rances
Locating Grill/Built-In Clea rances INSULATED JACKET: Do not build the Grill under overhead unprotected combustible construction. If the Grill is to be placed into a combustible enclosure, an approved insulated jacket is necessary and is available from your dealer. Use only the DCS insulated jacket which has specifically been designed and tested for this purpose.
Page 10 Built -In Grill Clea rances FIG.03 27FS Models " GENERAL (36DS / 48DS MODELS): The Grill is designed for easy placement into masonry enclosures. For non-combustible applications the grill drops into the opening shown in (Fig. 05) and hangs from its side flanges. A deck is not required to support it from the bottom.When using the insulated jacket in a combustible enclosure application, see (Fig.
Page 11: Built-In Construction Details
Built In Const ruction Details FIG.05 36 / 48 Models...
Page 12: Built-In Construction Details
Built In Const ruction Details FIG.06 27F Models " "...
Page 13: Leak Testing
Leak T esting GENERAL: Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks, or immediately check if the smell of gas is detected.
Page 14: Installer Final Checklist
Installe r Checklist/Bu rne r Ad justments INSTALLER FINAL CHECKLIST: ❏ ❏ ❏ Specified clearances main- Air shutters adjusted. Unit tested and free of leaks. tained to combustibles. ❏ ❏ Adjustable low setting satis User informed of gas supply ❏ Nylon straps removed from factory.
Page 15: Burner Adjustments
Bu rne r Ad justments /Using The Grill WARNING: IMPORTANT! Before lighting . . .Inspect the gas supply piping or hose prior to turning the gas "on". If there is evidence of cuts, wear, or abrasion, it must be replaced prior to use.
Page 16: Using The Grill
Using The Grill The replacement pressure regulators and hose assembly must be the type specified by the manufacturer. Do not use the grill if the odor of gas is present.The pressure regulator and hose assembly supplied with the unit must be used. If the unit is L.P., screw the regulator into the tank and leak check the hose and regulator connections with a soap and water solution before operating the grill.
Page 17: Lighting Instructions
Using The Grill/Lighting Inst ructions USING THE GRILL L.P. GAS: Grilling requires high heat for searing and proper browning. Most foods are cooked at the “Medium” heat setting for the entire cooking time. However, when grilling large pieces of meat or poultry, it may be necessary to turn the heat to a lower setting after the initial browning.This cooks the food through without burning the outside.
Page 18: Flame Height
Lighting / Rangetop Bu rne r Inst ructions Once the left or right burner is lit, the adjacent burner(s) can be lit by the cross-lighting method. For center burners to cross light, light the adjacent far left or right burner using the standard or match light procedure.
Page 19: Using The Smoker System
Using The Smoke r System 36/ 48 MODELS ONLY: FIG. 17 36 / 48 Grill Smoker System The smoker system on each grill consists of a stainless steel slide out tray which is positioned above a 5,000 BTU burner.The burner is controlled by a precision brass valve which is capable of being turned down to very low heat levels.The system may be used alone for low temperature roasting and smoking or in conjunction with any...
Page 20: Using The Rotiserrie Burner
Using The Rotisse rie Bu rne r BQRS AND BQARS SERIES ONLY: FIG. 20 36 / 48 Grill Rotisserie System The grill rotisserie system is designed to cook items from the back using infrared heat. The location of the burner allows the placement of the rotis basting pan (included) beneath the food to collect juices and drippings for basting and gravy.
Page 21 Using The Rotisse rie Bu rne r Open the lid. Push and turn the control knob to the “Lite” position. Press the safety valve button, hold in, and begin turning the rotary igniter button located next to the rotis knob. It may be necessary to turn the igniter knob several times until the burner lights.
Page 22: Care & Cleaning
Ca re And Cleaning GRILL RACKS: The easiest way to clean the grill is immediately after cooking is completed and after turning off the flame.Wear a barbeque mitt to protect your hand from the heat and steam. Dip a fine brass bristle barbeque brush in tap water and scrub the hot grill.
Page 23: Burner Removal
Bu rne r Removal And Cleaning RANGETOP BURNERS: FIG. 22 The grill power burners (BQRS Models Only) are cast iron and occasionally it will be necessary to remove surface rust to ensure proper performance. Frequency of cleaning will depend on the climate &...
Page 24: Troubleshooting
Troubleshooting Turn the igniter knob. If the igniter is good, a spark will jump across to the screwdriver. If no spark, replace the igniter. If there is a spark, examine the wire of the electrode for cracks and cuts. Also examine the electrode for grease and debris or see if the electrode tip is bent.
Page 25: Parts Lists
Grill Bu rne r Assembly ITEM DESCRIPTION PART NO. Grill Rack S/S 27F 19014-02 Grate 36/48 S/S 18197-01 Grate 36/48 18197 Radiant 32218-02 Ceramic Rods 32224 Radiant Cap 32264 6a 27”C/ Heat Shield w/Assy. 32220 C/Heat Shield w/Assy. 32268 7a SS Grill Burner 32217 7b Air Shutter Screw 12003-2...
Page 26: Grill Body Parts List
Grill Body Pa rts List ITEM DESCRIPTION PART NO. Roll Top Lid 48DBQ/36DBQA 32293-01 Logo Spring Clip 15073 Roll Top Lid 48DBQA 32293-02 Valve Panel 48DBQR 32212-01-PA Roll Top Lid 36DBQ 32293-03 Valve Panel 48DBQAR 32212-02-PA Roll Top Lid 27DBQR 30602-27 Valve Panel 48DBQ 32212-07-PA...
Page 27: Grill Body Assembly
Grill Body Pa rts List 355fig.05.eps...
Page 28: Rotiserrie Assembly / Parts List
Rotisse rie Assembly ITEM DESCRIPTION PART NO. Rotisserie Motor 27D 32069-02 Rotisserie Handle 18040 Rotisserie Motor Bracket 27F 32346 Meat Holder Assembly 19010-02 15021-09 Rotisserie Rod 48dbqar 19054-05 Bolts 15150 Rotisserie Rod 48dbqr 19054-02 Thermocouple 13007-2 Rotisserie Rod 36dbqar 19054-04 Electrode Rotisserie 13055-5 Rotisserie Rod 36dbqr...
Page 29: Smoker Burner Assembly / Parts List
Smoke r Bu rne r Assembly ITEM DESCRIPTION PART NO. Smoker Tray w/assembly 32231 Screw 15139 Screw 15139 Smoker /Burner Support 32226 Smoker Plate 32228 Control Valve 13017-01 Smoker Pull Handle 18204-01 Orifice L.P. 13005-71 Screw 15139 Orifice Natural 13005-59 Electrode Smoker 13012-6 Bezel...
Page 30: Grill Cart Assembly / Parts List
48 Grill Ca rt Pa rts list ITEM DESCRIPTION PART NO. Axle 41062 Side Shelf Tray 41067 8” Solid Rubber Wheel 18264 Side Shelf End Cap 14205 Hub Cap 41075-01-SP Side Shelf Assembly 18212 Torx Screw 15002-45 Bolt 15003-06 Right Door Assembly 41098-02 Left Body Panel 41053...
Page 31: Grill Cart Assembly / Parts List
36 Grill Ca rt Pa rts List ITEM DESCRIPTION PART NO. Pull Handle 18204-02 Side Shelf Tray 41067 Right Door Assembly 41113-01 Side Shelf End Cap 14205 Screw 15001-13 Side Shelf Assembly 18212 Door Stop Tab 41094 Bolt 15003-06 Hex Bolt 15002-17 Left Body Panel 41053...
Page 32: Grill Cart Assembly / Parts List
27F Grill Ca rt Pa rts List ITEM DESCRIPTION PART NO. Front Door Panel 41139 Hub Cap 41075-SP Pull Handle 18204-01 Wheel 18098 Door Liner 41140 Axle Spacer 41151 Spring 15198-01 Axle 41150 Keps Nut 15021-04 Side Panel R/H 41145-02 Washer Nylon 15199 Bottom Panel...
Page 33: Service
Se rvice HOW TO OBTAIN SERVICE: BEFORE YOU CALL FOR SERVICE: See page 21, follow troubleshooting guide first, then call for service if not resolved. For warranty service, contact your local DCS authorized service agency. Provide him with the Model Number, Serial Number, and date of installation, and a brief description of the problem.
Page 34: Warranty
Wa r ranty LENGTH OF WARRANTY: One (1) Year Full parts and Labor Covers the entire product Five (5) Year comprehensive warranty covering the porcelainized cast iron rangetop burners, grill radiant assemblies, and drip pans. Should structural deterioration occur to the degree of non-performance, a replacement will be furnished.
Page 35 Notes...
Page 36 Notes...
Page 37 Notes...
Page 38 As product improvement is an ongoing process at DCS, we reserve the right to change specifications or design without notice. 5800 Skylab Road, Huntington Beach, CA 92647 Tel: (714) 372-7000 Part No. 17355 Rev. B Fax: (714) 372-7001 Customer Service (888) 281-5698 Litho in USA 12/2004 www.dcsappliances.com...
