Deerfield™ Kitchen Sink
Installation and User Guide
MODEL NUMBERS
5815W
Important :- Please quote the above model number(s) when ordering spares.
IMPORTANT!
Installer: This manual is the property of the customer and must
be retained with the product for maintenance and operational
purposes.
1037045

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Deerfield 5815W and is the answer not in the manual?

Questions and answers

Summary of Contents for Kohler Deerfield 5815W

  • Page 1 P4450005 Deerfield™ Kitchen Sink Installation and User Guide MODEL NUMBERS 5815W Important :- Please quote the above model number(s) when ordering spares. IMPORTANT! Installer: This manual is the property of the customer and must be retained with the product for maintenance and operational purposes.
  • Page 2: Table Of Contents

    P4450 CONTENTS DESCRIPTION ................. SAFETY : WARNINGS ............. DIMENSIONS ................SPECIFICATION ..............Plumbing Connections ............. INSTALLATION ................. Before You Begin ............. Install the Kitchen Sink - Self Rimming ......Install the Plumbing ............USER MAINTENANCE ............Cleaning ................SPARE PARTS ................. CUSTOMER SERVICE ............
  • Page 3: Description

    Periodic attention is given, as necessary, to maintain the product in good functional order. Recommended guidelines are given in the MAINTENANCE section. Carefully inspect the new fixture for any signs of damage. When installing Kohler Products, manufacturers guidelines for power tool safety should be followed. 1037045...
  • Page 4: Dimensions

    P4450 DIMENSIONS All Dimensions in mm P4450010 1037045...
  • Page 5: Specification

    P4450 SPECIFICATION Plumbing Connections Hot (H) and Cold (C) inlets must be connected to the correct inlet supplies. INSTALLATION Before You Begin Turn off the water supply. plumbing installation must comply with Water Supply Regulations/Bye-laws (Scotland), Building Regulations or any particular regulations and practices, specified by the local water company or water undertakers.
  • Page 6: Install The Kitchen Sink - Self Rimming

    P4450 Install the Kitchen Sink - Self Rimming Before installing the sink make sure there is adequate clearance between the taps, the backsplash, the fixture and the cabinet. Make sure that the countertop is clean and dry. Installation Template P4345020 Cut out the installation template.
  • Page 7 P4450 Illustration may not be the same as product being installed Seal cut edges with a moisture resistant sealer P4345040 Caution! Cast Iron sinks are very heavy, so make sure two people lift the sink into position. Fit the taps in accordance with the manufacturer’s instructions. Install the drain in accordance with the manufacturer’s instructions.
  • Page 8 P4450 Silicone Sealant P4345050 11. Remove any excess silicone sealant and fill in any voids as required. 12. Allow the silicone sealant to cure before proceeding with the installation. 1037045...
  • Page 9: Install The Plumbing

    P4450 Install the Plumbing Gasket Gasket P4345070 Caution! Make sure a watertight seal exists on all sink drain connections. Caution! Provide access to the plumbing connections for future plumbing maintenance. Connect the drain to the waste pipe. Connect the hot and cold water supplies. Open the hot and cold water valves, and check the supply connections for leaks.
  • Page 10: User Maintenance

    P4450 USER MAINTENANCE Cleaning Caution! Risk of product damage. Many cleaners contain abrasive and chemical substances, and should not be used for cleaning stainless steel, enamel, plated or plastic fittings. These finishes should be cleaned using a mild washing up detergent or soap solution, rinsed and then wiped dry with a soft clean cloth.
  • Page 11: Spare Parts

    P4450 SPARE PARTS 5815W P4450020 1037045...
  • Page 12: Customer Service

    Kohler items you have purchased. Within the guarantee period we will undertake to resolve any material defects, by providing replacement parts, modules or complete product, as we deem appropriate. To be free of charge, work must only be undertaken by Kohler UK approved personnel.
