QuickSpecs
Configuration
Support Support Support Support
Hardware Requirements Hardware Requirements Hardware Requirements Hardware Requirements
SMS and Console Support
There is only one choice of SMS for Integrity Superdome: HP Superdome SMS PC solution (A9802D)
NOTE: As of 10/1/2007, the rx2620 based SMS is no longer offered. NOTE: NOTE: NOTE:
NOTE: As of 9/1/2009, the Windows ProLiant SMS/Console is no longer offered. NOTE: NOTE: NOTE:
The Windows PC based SMS:
Allows local access to SMS by CE.
Provides integrated console access, providing hpterm emulation over telnet and web browser,
connecting over LAN or serial to a Superdome system
Provides remote access over a LAN or dialup connection:
ftp server with capability to ftp the firmware files and logs
dialup modem access support (i.e., PC Anywhere or VNC)
Provides seamless integration with data center level management.
Provides partition logon capability, providing hpterm emulation over telnet, X windows, and
Windows Terminal Services capabilities.
Provides following diagnostics tools:
Runs HP's proven highly effective JTAG scan diagnostic tools, which offer rapid fault resolution to
the failing wire.
Console log storage and viewing
Event log storage and viewing
Partition and memory adviser flash applications
Supports updating platform and system firmware.
Always on event and console logging for Superdome systems, which captures and stores very long
event and console histories, and allows HP specialists to analyze the first occurrence of a problem.
Allows more than one LAN connected response center engineer to look at SMS logs
simultaneously.
Can be disconnected from the Superdome systems and not disrupt their operation.
Provides ability to connect a new Superdome system to the SMS and be recognized by scan
software.
Scans one Superdome system while other Superdome systems are connected (and not disrupt the
operational systems).
Supports multiple, heterogeneous Superdome platforms.
The Windows PC based SMS/Console is comprised of a HP rp5700 desktop PC and a TFT7600
retractable display monitor/keyboard/mouse to enable console access. This solution also requires (and
includes) a switch. This is because scan diagnostics will not work properly if more than one IP address
exists on the PC SMS/Console. The PC based SMS, by default, provides console functionality.
Additionally, the Windows PC SMS/Console includes an internal modem that is intended for connection
to a phone line. This is for cases in which the Customer does not want the SMS to be on a public
network, and HP Field Services needs to access the SMS (they would then access the SMS via the phone
line and PCAnywhere.)
A customer may not substitute any PC running Windows Server Vista for the PC SMS/Console due to the
specialized software applications that have been qualified on the hardware and OS. Utilizing any other
device as the SMS will void the warranty on the Superdome system and degrade the ability to service the
system.
The Windows PC SMS bundle is comprised of:
