6 language
Shows the active language for the Advanced User Interface� Select a
desirable language by clicking one of the available languages�
7 Version Info
Shows the firmware version, boot-code version, hardware version, and
serial number of the Router�
8 laN settings
Shows you the settings of the Local Area Network (LAN) side of the Router�
Changes can be made to the settings by clicking on any one of the links
(IP Address, Subnet Mask, DHCP Server) or by clicking the "LAN" quick-
navigation link on the left side of the screen�

150N Wireless Router

1 2 3 4 5 6
9 Internet settings
Shows the settings of the Internet/WAN side of the Router that connects to
the Internet� Changes to any of these settings can be made by clicking on
the links or by clicking on the "Internet/WAN" quick-navigation link on the
left side of the screen�
10 features
Shows the status of the Router's, firewall, and wireless features� Changes
can be made to the settings by clicking on any one of the links or by
clicking the quick-navigation links on the left side of the screen�
11 Page Name
The page you are on can be identified by this name� This User Manual will
sometimes refer to pages by name� For instance "LAN > LAN Settings"
refers to the "LAN Settings" page�
