Vertex Standard VX-3R Operating Manual

Vertex Standard VX-3R Operating Manual

Micro-miniature multiband fm transceiver
Hide thumbs Also See for VX-3R:

Advertisement

Quick Links

Download this manual See also: Technical Supplement
The VX-3R is a micro-miniature multiband FM transceiver with extensive receive frequency coverage,
providing local-area two-way amateur communications along with unmatched monitoring capability.
The VX-3R's incredibly small size allows you to take it anywhere - hiking, skiing, or while walking around
town - and its operating flexibility brings the user many avenues of operating enjoyment. Its incredibly tiny
FNB-82LI Lithium-Ion Battery Pack provides up to 1.5 Watts of transmit power on VHF, and 1 Watt on UHF.
Besides 144- and 430-MHz transceive operation, the VX-3R provides receive coverage of the AM (MF)
which provide the internal bar antenna and FM broadcast bands, HF Shortwave Bands, VHF and UHF TV
bands, the VHF AM aircraft band, and a wide range of commercial and public safety frequencies!
Furthermore, the VX-3R provides the internal bar antenna for the good receiving the AM broadcast.
Additional features include an Enhanced Paging and Code Squelch (EPCS), which allows you to page a
particular station and only receive calls from that station, if desired; a security Password feature, which will
allow you to turn on and operate your transceiver only after you enter your Password; a convenient access
key for Vertex Standard's WIRES
Automatic ID (EAI) function, that will automatically cause your VX-3R to transmit your callsign and engage
your rig's microphone, even if you are disabled and unable to press the PTT switch; a transmit Time-Out
Timer (TOT); Automatic Power-Off (APO); Automatic Repeater Shift (ARS); Yaesu's exclusive ARTS
(Auto-Range Transponder System) which "beeps" the user when you move out of communications range
TM
with another ARTS
channel congestion. And an S-meter squelch circuit allows the owner to set the squelch to open at a
programmable setting of the S-Meter, thus reducing guesswork in setting the squelch threshold.
We appreciate your purchase of the VX-3R, and encourage you to read this manual thoroughly, so as to
learn about the many exciting features of your exciting new Yaesu hand-held transceiver!
Supplied Accessories
FNB-82LI
NC-85A/B, C, U*
YHA-66
Operating Manual
Warranty Card
Available Options
FNB-82LI
FBA-37
General Description
™
(Wide-Coverage Internet Repeater Enhancement System); Emergency
equipped station, plus provision for reduction of the TX deviation in areas of high
Accessories & Options
3.7 V, 1000 mAh Rechargeable Lithium Ion Battery Pack
2.5-Hour Charger
Antenna
3.7 V, 1000 mAh Rechargeable Lithium Ion Battery Pack
Dry Cell Battery Case for 3 x "AA" Alkaline Cells
1
FCC ID: K6620285X20
IC ID: 511B-20285X20
VX-3R Operating Manual
Vertex Standard Co., Ltd.
™
