SYNC TIMING LIMITS

The Quadro Sync board has the ability to align displays and sync sources up to ±20 ppm
difference in the display timings. If the timings are outside this range the board will not
be able to synchronize them. The Frame Lock status LEDs on the board will indicate that
the board is approaching these limits as well.
Table 1. Sync Timing Limits
Display Refresh Rate (Hz)
200
120
100
60
50
Quadro Sync
Minimum (Hz) Maximum (Hz)
199.996 200.004
119.9976 120.0024
99.998 100.002
59.9988 60.0012
49.999 50.001
DU-06574-001_v01 | 28
