DELL
T M
OPTIPLEX 160
T M
TECHNICAL GUIDEBOOK
INSIDE THE OPTIPLEX 160

Advertisement

Table of Contents
loading

Related Manuals for Dell OPTIPLEX 160

Summary of Contents for Dell OPTIPLEX 160

  • Page 1 DELL OPTIPLEX 160 TECHNICAL GUIDEBOOK INSIDE THE OPTIPLEX 160...

  • Page 2: Table Of Contents

    O V E R V I E W OptiPlex 160 Tiny Desktop Computer View M A R K E T I N G S Y S T E M C O N F I G U R A T I O N S...
  • Page 3 Understanding that often the optimal flexible computing approach is a combination of solutions, Dell developed the new OptiPlex FX160 flexible computing node that is optimized for two of Dell’s Flexible Computing Solutions: On-Demand Desktop Streaming or Virtual Remote Desktop. In doing so, customers can now confidently invest in a client device that supports the right solution for today with the flexibility to support the needs of tomorrow.

  • Page 4: Optiplex 160 Tiny Desktop Computer View

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK OPTIPLEX 160 TINY DESKTOP COMPUTER VIEW F R O N T V I E W B A C K V I E W FRONT VIEW BACK VIEW 1 Power Button Microphone Connector Wireless Antenna PS/2 Keyboard Connector...
  • Page 5 DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK S Y S T E M B O A R D C O N N E C T O R S CONNECTORS Memory Connector (DIMM_1) Memory Connector (DIMM_2) Battery (BATTERY) SATA Data Cable Connector (SATA1)

  • Page 6: Marketing System Configurations

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK MARKETING SYSTEM CONFIGURATIONS N O T E : O f f e r i n g s m a y v a r y b y r e g i o n . OPERATING SYSTEM N O T E : O n e o f t h e f o l l o w i n g O p e r a t i n g S y s t e m s w i l l b e p r e i n s t a l l e d .

  • Page 7: Chipset, Processor, Memory

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK C H I P S E T SiSM671 Northbridge and SiS968 Southbridge Non-volatile memory BIOS Configuration FWH (firmware hub) 8Mbit flash IC located at U24 on motherboard TPM 1.2 Security Device (Trusted Platform Module) Not supported...

  • Page 8: Drives And Removable Storage

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK D R I V E S A N D R E M O V A B L E S T O R A G E N O T E : A n o p t i o n a l e x t e r n a l o p t i c a l d r i v e i s r e q u i r e d t o a c c e s s C D / D V D m e d i a . T h e D e l l r e s o u r c e a n d r e c o v e r y s o f t w a r e s h i p s o n a D V D r e q u i r i n g a t l e a s t a D V D - R O M ( o r D V D r e a d a b l e d r i v e ) t o a c c e s s a p p l i c a t i o n f i l e s / r e i n s t a l l O S .

  • Page 9: External Ports/Connectors

    N O T E : D e l l W i r e l e s s 1 3 9 7 i s a v a i l a b l e o n s e l e c t m o d e l s w i t h s u p p o r t i n g o p e r a t i n g s y s t e m s . Dell Wireless 1397 Half Mini PCIe (802.11bg) Card...

  • Page 10: Mounting Brackets/Stands

    Dell ProSupport Optional For a copy of our guarantees or limited warranties, please write Dell USA L.P., Attn: Warranties, One Dell Way, Round Rock, TX 78682. For more information, visit www.dell.com/warranty. Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts availability, geographical restrictions and terms of service contract.

  • Page 11: Detailed Engineering Specifications

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK DETAILED ENGINEERING SPECIFICATIONS S Y S T E M D I M E N S I O N S ( P H Y S I C A L ) N O T E : S y s t e m W e i g h t * a n d S h i p p i n g W e i g h t * i s b a s e d o n a t y p i c a l c o n f i g u r a t i o n a n d m a y v a r y b a s e d o n t h e c o m p u t e r c o n f i g u r a t i o n a n d i f t h e s t a n d i s i n c l u d e d .

  • Page 12: Power

    I N T E G R A T E D P O W E R S U P P L Y * * These form factors utilize a more efficient Active Power Factor Correction (APFC) power supply. Dell recommends only Universal Power Supplies (UPS) based on Sine Wave output for APFC PSUs, not an approximation of a Sine Wave, Square Wave, or quasi-Square Wave (see UPS technical specifications).

  • Page 13: Communications-Integrated Lan

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK A U D I O ( C O N T . ) INTEGRATED ADI 1984A HIGH DEFINITION AUDIO CODEC Audio Jack Impedance Microphone (input impedance) 23K ohms typical Line-In Line-Out Headphone (external load impedance) 32 ohms min...

  • Page 14: Communications-Wireless Lan

    Medium access protocol (ACK) IEEE 802.11b: 1,2,5.5,11 IEEE 802.11g: 1,2,5.5,6,9,11,12,18,24,36,48,54 Data rate (Mbps) NOTE: The Dell wireless WLAN card uses an automatic transmit rate select mechanism Radio Characteristics IEEE 802.11b: 2.4 GHz (2400-2500 MHz) Frequency band IEEE 802.11g: 2.4 GHz (2400-2500 MHz) IEEE 802.11b: direct sequence spread spectrum...

  • Page 15: Graphics/Video Controller

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK G R A P H I C S / V I D E O C O N T R O L L E R N O T E : V G A m a x i m u m r e q u i r e d a n d t e s t e d r e s o l u t i o n i s 1 9 2 0 x 1 2 0 0 .
  • Page 16 DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK 2.5” 20GB RBX SATA SOLID STATE DRIVE Capacity (bytes) 20,014,718,976 Dimensions inches (W x D x H) 3.94 x 2.75 x 0.374 Interface type and Maximum speed Up to 3Gb/s MTBF 2M hours Performance: Sequential Read/ Write 95/70 (MB/s) Performance: SYSmark ‘07 Overall Score...
  • Page 17 DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK 2.5” 80B SATA 7200 RPM HDD Capacity (bytes) 80,026,361,856 Dimensions inches (W x D x H) 3.93 x 2.75 x 0.374 Interface type and Maximum speed Up to 3Gb/s Internal buffer size (range) 16 MB...

  • Page 18: Optical Drive

    DELL™ OPTIPLEX™ 160 TECHNICAL GUIDEBOOK O P T I C A L D R I V E S EXTERNAL USB DVD-ROM External Dimensions W x H x D 142mm x 24mm x 160mm Weight (max) pounds/kilograms 0.43kg Interface type USB 2.0...

  • Page 19: Optimal System Placement

    S Y S T E M S P A C I N G The OptiPlex 160 is designed to have high performance while operating with low acoustics noise. This is made possible, in part, by the large amount of ventilation on the system.
  • Page 20 If the system is installed using the optional wall mount, ensure that none of the vents are blocked on the system. The OptiPlex 160 has ventilation on four of the 6 surfaces. Space the system so that there is adequate room for proper airflow, as defined by: Ensure there is at least 2 inches (50.8mm) between the top of the system and...
  • Page 21 Regulatory Datasheet for this product is located at: regulatory_compliance/reg_compliance?~ck=ln&c=us&l=en&lnki=0&s=corp Details of Dell's environmental stewardship program to conserve product energy consumption, reduce or eliminate materials for disposal, prolong product life span and provide effective and convenient equipment recovery solutions may be viewed at www.dell.com/environment.

  • Page 22: Acoustic Noise Emission Information

    1397 Half Mini-card Graphics Adapter Integrated Adapter Integrated Adapter The Declared Noise Emission in accordance with ISO 9296 for the Dell OptiPlex 160 is as follows (all values L expressed in bels; 1 bel=10 decibels, re 10 Watts) Typical Configuration...
