Kohler KD400 Specifications

Kohler KD400 Specifications

1 cylinder/401 cc/7.3 kw/9.8 hp/3600 rpm
Hide thumbs Also See for KD400:
1
2
3
4

Advertisement

Quick Links

Download this manual See also: Workshop Manual, Owner's Manual
1 Cylinder
401 cc
»
Certification
EPA TIER 2
ECE R 24
Features
4-Stroke Air-Cooled Diesel Engine
SEA J609a Crankshaft
Counter-Clockwise Rotation
Direct Injection
Full-Pressure Lubrication with Oil Pump
Centrifugal Mass Governor
Built-In Full-Flow Oil Filter
Oil Breathing Blow-By with Safety Device
Automatic Extra Fuel Starting Device
Self-Bleeding Fuel System
Torque Regulator
Automatic Compression Release
Die-Cast Aluminum Crankcase with Integral Cast Iron Cylinder Liner
Aluminum Cylinder Head
Mounting Feet
Hydraulic Valve Lifters
Applications
Two-Wheel Tractor
Agricultural Mower
Agricultural Pump
High-Pressure Cleaner
Generator
Vibrating Plate
Hydraulic Power Pack
Vibrating Roller
Relentless Power.
Legendary Performance.
Kohler ® Diesel
Model KD400
7.3 kW/9.8 HP
3600 RPM
»
»
22.5 ft. lbs. @2100 RPM
»
PAGE:
1
OF 4
© 2008 by Kohler Co.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KD400 and is the answer not in the manual?

Questions and answers

Related Manuals for Kohler KD400

Summary of Contents for Kohler KD400

  • Page 1 Die-Cast Aluminum Crankcase with Integral Cast Iron Cylinder Liner Aluminum Cylinder Head Mounting Feet Hydraulic Valve Lifters Applications Two-Wheel Tractor Agricultural Mower Agricultural Pump High-Pressure Cleaner Generator Vibrating Plate Hydraulic Power Pack Vibrating Roller Relentless Power. PAGE: OF 4 Legendary Performance. © 2008 by Kohler Co.

  • Page 2: Specifications

    (RPM) (mm) ≥ 650 [53+L (mm)] N (kW) n (RPM) Max. allowable axial load in both directions A-B = 200 kg/441 lb 1000 RPM 2000 RPM 3000 RPM 3600 RPM PAGE: OF 4 KohlerEngines.com © 2008 by Kohler Co.
  • Page 3 NB Power curve - ISO 3046/1 - IFN - NA Power curve - ISO 3046/1 - ICXN - Torque curve - (N curve) MB (B curve - MA (A curve) Specific fuel consumption - (NB curve) PAGE: OF 4 © 2008 by Kohler Co. KohlerEngines.com...
  • Page 4 Fuel Safety Shutdown for Low Oil Pressure with Type B Mtg. Flange Extended Wiring Harness PAGE: OF 4 KOHLER Co., Kohler, Wisconsin 53044 • Tel: 920-457-4441 800-544-2441 • Fax: 920-459-1570 • KohlerEngines.com Form TP-2611 5/08 © 2008 by Kohler Co. Printed in U.S.A.
