FORCE 12 Powered Mixer
OPERATING MANUAL AND USER GUIDE
www.wharfedalepro.com

Advertisement

Table of Contents
loading

Related Manuals for Wharfedale Pro Force 12

Summary of Contents for Wharfedale Pro Force 12

  • Page 1 FORCE 12 Powered Mixer OPERATING MANUAL AND USER GUIDE www.wharfedalepro.com...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ................1 IMPORTANT WARNINGS & SAFETY INFORMATIONS ......2 INTRODUCTION ..................3 ABOUT THE FORCE 12 ................3 FORCE 12 FEATURES ................3 CHANNEL CH1-6 ..................4 CHANNEL CH7-8 ..................5 CHANNEL CH9/10 ..................6 CHANNEL CH11/12...................

  • Page 4: Important Warnings & Safety Informations

    OPERATING MANUAL AND USER GUIDE IMPORTANT WARNINGS & SAFETY INSTRUCTIONS 1. Read these instructions 2. Follow all instructions 3. Keep these instructions 4. Heed all warnings 5. Do not use this apparatus near water 6. Clean only with dry cloth. 7.

  • Page 5: Introduction

    ABOUT THE FORCE 12 Designed to be a perfect balance of portability and power the FORCE 12 is suitable for use in a wide range of portable sound applications. Everything you need to mix and amplify microphones and line level sources is included in one box, with an ergonomic carry handle to aid transportation.

  • Page 6: Channel Ch1-6

    OPERATING MANUAL AND USER GUIDE Channel CH 1-6 Peak LED-----Illuminates when the signal in this channel starts clipping. Gain-----Gain control for the input signal for this channel. High-----High frequency shelving EQ at 12 kHz. Mid-----Mid frequency shelving EQ at 2 kHz. Low-----Low frequency shelving EQ at 80 Hz.

  • Page 7: Channel Ch7-8

    FORCE 12 Powered Mixer Channel CH 7-8 Peak LED-----Illuminates when the signal in this channel starts clipping. Gain-----Gain control for the input signal for this channel. High-----High frequency shelving EQ at 12 kHz. Mid-----Mid frequency shelving EQ at 2 kHz.

  • Page 8: Channel Ch9/10

    OPERATING MANUAL AND USER GUIDE Channel CH 9/10 Peak LED-----Illuminates when the signal in this channel starts clipping. Gain-----Gain control for the input signal for this channel. High-----High frequency shelving EQ at 12 kHz. Low-----Low frequency shelving EQ at 80 Hz. Mon-----Mon sends signal to a stage monitor.

  • Page 9: Channel Ch11/12

    FORCE 12 Powered Mixer Channel CH 11/12 Peak LED-----Illuminates when the signal in this channel starts clipping. Gain-----Gain control for the input signal for this channel. High-----High frequency shelving EQ at 12 kHz. Low-----Low frequency shelving EQ at 80 Hz.

  • Page 10: Force 12 Master Section

    OPERATING MANUAL AND USER GUIDE FORCE 12 MASTER SECTION Peak LED-----Illuminates when the Effects clipping LED Digital Display -----56 sorts of stereo effects can be displayed via LED digital display FX Send-----Allows for master adjustment of the FX send bus.

  • Page 11: Force 12 Master Section

    FORCE 12 Powered Mixer FORCE-12 MASTER SECTION 1: Record Out-----Line level output using phonograph connectors provide connection to recording devices. 2: FX Send----- Sends the mixed signal to the outside effect processor. 3: FX Foot Switch -----Controls the internal FX processor on or off by a foot switch.

  • Page 12: Force 12 Rear Panel

    OPERATING MANUAL AND USER GUIDE FORCE 12 REAR PANEL Phantom power switch-----Activates the +48v phantom power for the 8 Mic channels Power switch-----Turns the unit on or off. Ensure that AC is supplied and the levels have been turned down to protect your speakers.

  • Page 13: Dimensions

    FORCE 12 Powered Mixer DIMENSIONS 535.79 330.86...

  • Page 14: Usb Interface

    CD quality, ensuring that recordings that you make with a FORCE 12 have outstanding quality. The FORCE 12 is fully class compliant and requires no drivers when used with modern operating systems. Mac OSX, Windows XP, Vista and 7 will require no additional driver software.

  • Page 15: Wiring Diagrams

    FORCE 12 Powered Mixer WIRING DIAGRAMS...

  • Page 16: Block Diagram

    OPERATING MANUAL AND USER GUIDE BLOCK DIAGRAM...

  • Page 17: Specifications

    FORCE 12 Powered Mixer SPECIFICATIONS Model FORCE 12 Power Output 500W*2 RMS into 4 ohms(THD=1%@ 1KHz) 550W*2 RMS into 4 ohms(THD=5%@ 1KHz) 260W*2 RMS into 8 ohms(THD=1%@ 1KHz) 290W*2 RMS into 8 ohms(THD=5%@ 1KHz) 1300W*2 Peak into 4 ohms 700W*2 Peak into 8 ohms...

  • Page 18: Wharfedale Pro Limited Warranty

    IAG HOUSE, Sovereign Court, Ermine Business Park Huntingdon, Cambs, PE29 6XU, England www.wharfedalepro.com Wharfedale Professional reserves the right to alter or improve specifications without notice. All rights reserved © 2011 Wharfedale Pro. Wharfedale Pro is a member of the IAG Group.
