Summary of Contents for Wharfedale Pro M16

  • Page 1 DIGITAL MIXING CONSOLE USER MANUAL AND USER GUIDE GAIN GAIN GAIN GAIN GAIN GAIN GAIN GAIN 60dB 60dB 60dB 60dB 60dB 60dB 60dB 60dB GAIN GAIN GAIN GAIN GAIN GAIN GAIN GAIN 60dB 60dB 60dB 60dB 60dB 60dB 60dB 60dB SYSTEM DEFINED IN 1-8...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ........................1 COMMONLY USED CONNECTIONS ................2 FRONT PANEL ........................3 REAR PANEL ........................4 SPECIFICATION-1 .......................5 SPECIFICATION-3......................6 DIMENSIONS ........................7 MIC – EDIT 1 ........................8 MIC – Edit 2 ........................9 MIC – EQ ..........................10 MIC – EQ LIBRARY......................11 MIC – COMPRESSOR......................12 SYSTEM..........................13 SETUP –...
  • Page 3: Introduction

    Introduction The M16 mixer is a unique and innovative multi-functional digital mixing console,with many advantages such as small size,light weight, intuitive and simple operation, user friendly interface and a premium touch screen. The flagship hardware configuration uses 4th generation industrial floating-point SHARC processing. This delivers 24bits/192kHzAD/DA and powerful interface performance to ensure the highest possible audio quality.
  • Page 4: Commonly Used Connections

    Commonly Used Connections Centre Talkback In Ear Dynamic Gooseneck Wireless Electric Control microphone microphone microphone guitar Interface CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Direct Box 24V/DC INPUT AES/EBU DIGITAL MIXING CONSOLE Interface Electric Acoustic Stage Monitor 45°Monitor Laptop Processor Keyboard Saxophone piano guitar...
  • Page 5: Front Panel

    Front Panel 1. Gain: These are analogue gain controls. The gain setting will remain unchanged regardless of scene changes. 2. USB: Record/play, scene import/export, system update, WI-FI GAIN GAIN GAIN GAIN GAIN GAIN GAIN GAIN 60dB 60dB 60dB 60dB 60dB 60dB 60dB 60dB...
  • Page 6: Rear Panel

    Rear Panel CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN 24V/DC INPUT AES/EBU DIGITAL MIXING CONSOLE 1. RS232: Send and receive serial port control signals through the standard RS232 serial port protocol. 2. Power input port: 24V power supply interface. Always use the factory supplied power adapter. 3.
  • Page 7: Specification-1

    Specification-1 MIC INPUTS 16 channel inputs (balanced) 16 XLR and 4 COMBO inputs Mic input connector Input impedance XLR 3kΩ Frequency Response 20Hz–20kHz (+/-0.5dB) MIC INPUTS Max. Input Level +20dBu (balanced) S/N Ratio 105dB Gain Range 70dB 0.005% Phantom power +48V (CH-1 to CH-16) Line Inputs 4 COMBO inputs...
  • Page 8: Specification-3

    Specification-3 Main Outputs ( Balanced ) 8 assignable outputs XLR L/ R + 4 Mono Busses + 4 Stereo Busses TH D 0.0 0 5 %( 2 0 H z –2 0 k H z ) Frequency Response 2 0 H z –2 0 k H z ( + / - 0. 5 d B ) XLR OUTPUTS Max .
  • Page 9: Dimensions

    Dimensions GAIN GAIN GAIN GAIN GAIN GAIN GAIN GAIN 60dB 60dB 60dB 60dB 60dB 60dB 60dB 60dB GAIN GAIN GAIN GAIN GAIN GAIN GAIN GAIN 60dB 60dB 60dB 60dB 60dB 60dB 60dB 60dB SYSTEM DEFINED CAUTION IN 1-8 IN 9-16 OUT 1-8 RISK OF ELECTRIC SHOCK DO NOT OPEN...
  • Page 10: Mic - Edit 1

    MIC – Edit 1 M I C 3 - E d i t Edit COMP C O P Y L I N K MIC3&4 F X I N S E R T 0.0 dB 4 8 V Modul 2 Delay 1 Modul 1 Delay 2 Reverb...
  • Page 11: Mic - Edit 2

    MIC – Edit 2 MIC 3-E dit Edit COMP C OP Y L INK MIC3&4 F X I NS E R T 0.0 dB Modul 2 Delay 1 Modul 1 Delay 2 Reverb 1 Reverb 2 G E Q 1 G E Q 2 Gain AUX1...
  • Page 12: Mic - Eq

    MIC – EQ MIC 1-E Q Edit COMP C OP Y LINK MIC3&4 0.0 dB 1. 4 Bands PEQ Graph. Freq:22Hz Gain:-18.0dB The EQ Graph has 4 draggable selection Q :3.0 points.This allows the user to quickly adjust the selected band Frequency 80 100 300 400 500 600 800 1K 4K 5K 6K...
  • Page 13: Mic - Eq Library

    MIC – EQ Library MIC 1-E Q MIC 1-E Q EQ Library Page: Edit Edit COMP COMP C OP Y C OP Y LINK LINK MIC3&4 MIC3&4 This page contains a list of the functions 0.0 dB Library 3 Time and library files for the PEQ library.
  • Page 14: Mic - Compressor

    MIC - Compressor MI C 1-C omp Edit COMP C O P Y L I NK MIC3&4 Range Reduction 0.0 dB Compressor G a te -10dB -10dB -20dB -20dB -30dB -30dB -40dB -40dB -50dB -50dB -60dB -60dB Threshold Attack R elease Threshold Gain Ratio...
  • Page 15: System

    System 1. Scene Displays the current scene name, Music Show 21:20:30 2016/12/18 date and time. IP Address:192.168.20.1 AP K : 3. 0 0.0 dB System 2. System Information Oscillator Destination Wi - Fi AP/Hotspot Monitor/Phone Displays the mixer IP address and AUX1 White noise Update...
  • Page 16: Setup-Wifi

    Change the SSID name and password to setup the AP/Hotspot. iPAD Setting 1. Download the Wharfedale Pro M16 app from the iPAD OS app store. https://apps.apple.com/gb/app/m16-mixer/id1474073087 2. Ensure the iPad is connected to the same network as per the mixer setting - or select the AP SSID name set in the mixer.
  • Page 17: Setup - Scene

    Setup - Scene Music Show 21:20:30 2016/12/18 E xport Music Show Time System Delete New - Show 1 2016.11.28 00:01:26 Scene Page New - Show 2 2016.11.28 00:01:26 Scenes Music Show 2016.11.28 00:01:26 1. Scene List Copy Player The scene list contains the serial number, Rename Setup selection, name,creation or update time.
  • Page 18: Setup - Multimedia

    Setup - Multimedia Music Show 21:20:30 2017/12/18 System Adele USB TO BUS System Adele-Rolling inthe deep US B DIG I GROUP1 13: 01 Adele-S omeone like you GROUP2 Record Play Scenes T rim Adele-S kyfall GROUP3 GROUP4 0. 0 d B Player L&R F ader...
  • Page 19: Setup-Fx Assign

    Setup-FX Assign FX Assign: Music Show 21:20:30 2016/12/18 This page allows the user to add the FX or GEQ module to the Inputs or Output channel quickly without going System F X A s s ign Output P atch Defined L ayer Mute G roup through 'channel by channel'.
  • Page 20: Setup - Define Layer

    Setup – Define Layer The M16 system provides a User Define layer Music Show 21:20:30 2016/12/18 option to allow the user to customise a page with 8 channels. The User Define layer can be made System F X A s s ign...
  • Page 21: Fx - Modulation

    FX - Modulation Music Show 21:20:30 2016/12/18 Modul 1 Library 0.0 dB System HP F LP F F X -P res et S low c horus Scenes Dry-Wet S peed 0. 0 0. 0 Player Intens ity Setup 0. 0 Meters G ain F reqency...
  • Page 22: Fx - Dela

    FX - Delay 1. Preset Music Show 21:20:30 2016/12/18 Click the down drop to select the preset. The list includes: Delay1 Library 0.0 dB System One echo 1/4, Two echo 1/8, Three echo HP F LP F F X -P res et 1/16, Three echo 1/16 Delayed, Four echo 1&...
  • Page 23: Fx-Geq

    FX-GEQ 1. The level of all frequencies are set Music Show 21:20:30 2016/12/18 to 0dB by default. Use either the G E Q 1 Library 0.0 dB System on-screen fader or the mixer fader to adjust the value. 31.5 Scenes 2.
  • Page 24 Wharfedale Professional IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK www.wharfedalepro.com Wharfedale Professional reserves the right to alter or improve specifications without notice. All rights reserved © 2019 Wharfedale Pro. Wharfedale Pro is a member of the IAG Group.
