- Page 1 120-VOLT COMPACT ELECTRIC DRYER Use & Care Guide For questions about features, operation/performance parts, accessories or service, call: 1-800-253-1301. or visit our website at... www.crosley.com Table of Contents ..........2 8578917...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DRYER SAFETY................3 Stopping and Restarting ............10 Loading..................11 INSTALLATION INSTRUCTIONS ..........4 Drying, Cycle, and Temperature Tips ........11 Tools and Parts ................4 Cycles ..................11 Location Requirements ..............4 Electrical Requirements ...............6 DRYER CARE................12 Venting Requirements..............6 Cleaning the Dryer Location............12 Plan Vent System .................7 Cleaning the Lint Screen ............12 Install Vent System...............8 Cleaning the Dryer Interior ............12... -
Page 3: Dryer Safety
DRYER SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Tools and Parts Location Requirements Tools needed WARNING Gather the required tools and parts before starting installation. Read and follow the safety instructions provided with any tools listed here. Flat-blade screwdriver Caulking gun and compound (for installing Level new exhaust vent) Adjustable wrench Tin snips (new vent... - Page 5 Dryer Dimensions Recessed or closet installation - Dryer only " 14" (52.7 cm) (35.6 cm) 18"(45.7 cm) 31" † (78.7 cm) 3" 0" 0" (7.6 cm) (0 cm) (0 cm) A. Side view - closet or confined area " B. Recessed area (60.6 cm) Recessed or closet installation - Stacked †Height with caster is 32½"...
-
Page 6: Electrical Requirements
Electrical Requirements Venting Requirements WARNING WARNING Fire Hazard Electrical Shock Hazard Use a heavy metal vent. Plug into a grounded 3 prong outlet. Do not use a plastic vent. Do not remove ground prong. Do not use a metal foil vent. Do not use an adapter. -
Page 7: Plan Vent System
An exhaust hood should cap the vent to prevent rodents and Alternate installations for close clearances insects from entering the home. Venting systems come in many varieties. Select the type best for your installation. Two close-clearance installations are shown. Exhaust hood must be at least 12" (30.5 cm) from the ground or Refer to the manufacturer’s instructions provided with the vent any object that may be in the path of the exhaust (such as system. -
Page 8: Install Vent System
Determine vent length IMPORTANT: Do not use vent runs longer than specified in the Vent Length Chart. 1. Select the route that will provide the straightest and most direct path outdoors. Plan the installation to use the fewest In the column listing the type of metal vent you are using (rigid number of elbows and turns. -
Page 9: Connect Vent
2. Insert cord brackets into slotted holes in rear panel and secure with screws provided. Connect Vent 1. Using a 4" (10.2 cm) clamp, connect vent to exhaust outlet in dryer. If connecting to existing vent, make sure the vent is clean. -
Page 10: Dryer Use
DRYER USE Before using your dryer, wipe the dryer drum with a damp cloth to Starting Your Dryer remove dust from storing and shipping. 1. Clean the lint screen before or after each cycle. See “Cleaning the Lint Screen.” WARNING 2. -
Page 11: Loading
Loading Cycles Load clothes loosely into the dryer. Do not pack the dryer. Allow space for clothes to tumble freely. The following chart shows the maximum load you can place in your compact dryer. Expect longer drying times. Heavy work 2 pair of pants, 3 work shirts clothes Delicates... -
Page 12: Dryer Care
DRYER CARE To wash Cleaning the Dryer Location 1. Roll lint off the screen with your fingers. 2. Wet both the lint screen cover and body with hot water. Keep dryer area clear and free from items that would obstruct the flow of combustion and ventilation air. -
Page 13: Troubleshooting
TROUBLESHOOTING First try the solutions suggested here and possibly avoid the cost of a service call... Is the load properly sorted? Clothes are not drying satisfactorily Sort lint givers (towels, chenille) from lint takers (corduroy, synthetics). Also sort by color. The compact dryer operates at a lower wattage. -
Page 14: Assistance Or Service
United States. When calling, please know the purchase date and the complete To locate the Crosley designated service company in your area, model and serial number of your appliance. This information will you can also look in your telephone directory Yellow Pages. - Page 15 Notes...
-
Page 16: Dryer Warranty
YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE. ® Outside the 50 United States and Canada, this warranty does not apply. Contact your authorized Crosley dealer to determine if another warranty applies.
