Summary of Contents for Crosley Conservator CEDC392PQ0
- Page 1 120-VOLT COMPACT ELECTRIC DRYER Use & Care Guide For questions about features, operation/performance parts, accessories or service, call: 1-800-253-1301. or visit our website at... www.crosley.com Table of Contents ... 2 8562112...
-
Page 2: Table Of Contents
DRYER SAFETY...3 INSTALLATION INSTRUCTIONS ...4 Tools and Parts ...4 Location Requirements ...4 Electrical Requirements ...6 Venting Requirements...6 Plan Vent System ...7 Install Vent System...8 Install Cord Bracket and Casters...8 Connect Vent...9 Complete Installation ...9 DRYER USE ...10 Starting Your Dryer...10 TABLE OF CONTENTS Stopping and Restarting ...10 Loading...11... -
Page 3: Dryer Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Tools and Parts Tools needed Gather the required tools and parts before starting installation. Read and follow the safety instructions provided with any tools listed here. Flat-blade screwdriver Level Adjustable wrench Vent clamps Parts supplied Remove parts package from the dryer drum. Check that all parts listed are included. - Page 5 Dryer Dimensions (60.6 cm) †Height with caster is 32½" (82.6 cm) *Most installations require a minimum 5½" (14.0 cm) clearance behind the dryer for the exhaust vent with elbows. See “Venting Requirements.” Minimum installation spacing for recessed area and closet installation The following dimensions shown are for the minimum spacing allowed when the unit is to be operated with, or without, the...
-
Page 6: Electrical Requirements
4" (10.2 cm) heavy metal exhaust vent and clamps must be used. DURASAFE™ vent products are recommended. DURASAFE™ vent products can be purchased from your dealer or by calling Whirlpool Parts and Accessories. For more information, see the “Assistance or Service” section of this manual. -
Page 7: Plan Vent System
An exhaust hood should cap the vent to prevent rodents and insects from entering the home. Exhaust hood must be at least 12" (30.5 cm) from the ground or any object that may be in the path of the exhaust (such as flowers, rocks or bushes, etc.). -
Page 8: Install Vent System
Determine vent length 1. Select the route that will provide the straightest and most direct path outdoors. Plan the installation to use the fewest number of elbows and turns. When using elbows or making turns, allow as much room as possible. Bend vent gradually to avoid kinking. -
Page 9: Connect Vent
2. Insert cord brackets into slotted holes in rear panel and secure with screws provided. A. Cord bracket B. Slotted hole C. Screw NOTE: Power supply cord may be wrapped around the brackets for storage convenience when dryer is not in use. Install casters 1. -
Page 10: Dryer Use
Starting Your Dryer WARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Do not dry anything that has ever had anything flammable on it (even after washing). Failure to follow these instructions can result in death, explosion, or fire. -
Page 11: Loading
Loading Load clothes loosely into the dryer. Do not pack the dryer. Allow space for clothes to tumble freely. The following chart shows the maximum load you can place in your compact dryer. Expect longer drying times. Heavy work 2 pair of pants, 3 work shirts clothes Delicates 1 camisole, 2 slips, 4 undergarments,... -
Page 12: Dryer Care
Cleaning the Dryer Location Keep dryer area clear and free from items that would obstruct the flow of combustion and ventilation air. WARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Place dryer at least 18 inches (46 cm) above the floor for a garage installation. -
Page 13: Troubleshooting
First try the solutions suggested here and possibly avoid the cost of a service call... Clothes are not drying satisfactorily The compact dryer operates at a lower wattage. Expect longer drying times. Check the following: Is the wire exhaust guard removed from the back of the dryer? Is the lint screen clogged with lint? Is the exhaust vent or outside exhaust hood clogged with lint,... -
Page 14: Assistance Or Service
Before calling for assistance or service, please check “Troubleshooting.” It may save you the cost of a service call. If you still need help, follow the instructions below. When calling, please know the purchase date and the complete model and serial number of your appliance. This information will help us to better respond to your request. - Page 15 Notes...
-
Page 16: Dryer Warranty
For one year from the date of purchase, when this dryer is operated and maintained according to instructions attached to or furnished with the product, Whirlpool Corporation will pay for Factory Specified Parts and repair labor costs to correct defects in materials or workmanship.
