Summary of Contents for Crosley Conservator CEDC392JQ0
- Page 1 120-VOLT COMPACT ELECTRIC DRYER Use & Care Guide For questions about features, operation/performance, parts, accessories or service call: 1-800-253-1301 or visit our website at www.crosley.com Table of Contents...2 8521904...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DRYER SAFETY ... 3 PARTS AND FEATURES ... 4 INSTALLATION INSTRUCTIONS... 5 Tools and Parts ... 5 Location Requirements ... 5 Electrical Requirements ... 7 Venting Requirements... 7 Determine Vent Length ... 8 Begin Installation... 8 Install Vent System... 9 Connect Vent ... -
Page 3: Dryer Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: Parts And Features
1. Control panel 2. Model and serial number label 3. Dryer drum 4. Lint screen 5. Moisture sensor Control Panel PARTS AND FEATURES... -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Tools and Parts Tools needed Check that you have everything necessary for correct installation. Proper installation is your responsibility. flat bladed screwdriver safety glasses (optional) level duct tape adjustable wrench caulking gun and compound (for installing gloves (optional) new exhaust vent) tin snips (new vent installations) - Page 6 Recommended/Minimum Clearances Most installations require a minimum 5 in. (12.7 cm) clearance behind the dryer for the exhaust vent with elbows. See “Venting Requirements.” NOTE: Observe all governing codes and ordinances. (60.6 cm) †Height with casters is 32½” (82.6 cm). Recessed Area and Closet Installation Your dryer needs a certain amount of space around it for proper ventilation and for easier installation and servicing.
-
Page 7: Electrical Requirements
Electrical Requirements WARNING Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock. A 120-volt, 60-Hz., AC-only, 15- or 20- ampere fused electrical supply is required. -
Page 8: Determine Vent Length
Determine Vent Length NOTE: Check periodically to ensure that the outside exhaust hood is not blocked. The maximum length of the exhaust system depends upon: The type of vent (rigid metal or flexible metal). The number of elbows (90° turns) used. Recommended hood styles are shown here. -
Page 9: Install Vent System
4. Insert cord brackets into slotted holes in rear panel and secure with screws provided. NOTE: Power supply cord may be wrapped around the brackets for storage convenience when dryer is not in use. Install casters 1. Lay the dryer on its side. 2. -
Page 10: Complete Installation
Complete Installation 1. Check to be sure all parts are now installed. If there is an extra part, go back through the steps to see which step was skipped. 2. Check to be sure you have all of your tools. 3. -
Page 11: Stopping And Restarting
Before using your dryer, wipe the dryer drum with a damp cloth to remove dust from storing and shipping. 1. Load clothes loosely into the dryer and close the door. Do not pack the dryer. Allow space for clothes to tumble freely. 2. -
Page 12: Cycle Descriptions
CYCLE DESCRIPTIONS Cycle Control knob Permanent Press Cycle This automatic cycle shuts off the dryer when the selected dryness is reached. The Cycle Control knob does not move until the load is almost dry. After the cool down, the knob automatically turns to an Off area and tumbling stops. -
Page 13: Dryer Care
DRYER CARE Cleaning the Lint Screen Every load cleaning The lint screen is located inside the dryer drum, on the back wall. Clean it before each load. A screen blocked by lint can increase drying time. To clean 1. Open the door and pull the lint screen straight out. 2. -
Page 14: Troubleshooting
TROUBLESHOOTING First try the solutions suggested here and possibly avoid the cost of a service call... Clothes are not drying satisfactorily The compact dryer operates at a lower wattage. Expect longer drying times. Check the following: Is the wire exhaust guard removed from the back of the dryer? Is the lint screen clogged with lint? Is the exhaust vent or outside exhaust hood clogged with lint,... -
Page 15: Assistance Or Service
Whirlpool designated service technicians are trained to fulfill the product warranty and provide after-warranty service, anywhere in the United States. To locate the Whirlpool designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance... -
Page 16: Warranty
For one year from the date of purchase, when this dryer is operated and maintained according to instructions attached to or furnished with the product, Whirlpool Corporation will pay for Factory Specified Parts and repair labor to correct defects in materials or workmanship.
