INSTRUCTIONS-PARTS LIST
This manual contains IMPORTANT
WARNINGS and INSTRUCTIONS READ
AND RETAIN FOR REFERENCE
HYDRA-CLEAN 1026, 1530, 2340
Pressure Washers
HYDRA-CLEAN 1026, 3 HP ENGINE
P/N 800–682, Series A
1000 psi (69 bar) OPERA TING PRESSURE
1400 psi (97 bar) MAXIMUM WORKING PRESSURE
HYDRA-CLEAN 1530, 4 HP ENGINE
P/N 800–717, Series A
1500 psi (103 bar) OPERA TING PRESSURE
1900 psi (131 bar) MAXIMUM WORKING PRESSURE
HYDRA-CLEAN 2340, 8 HP ENGINE
P/N 800–654, Series A
2300 psi (159 bar) OPERA TING PRESSURE
2800 psi (193 bar) MAXIMUM WORKING PRESSURE
1026
GRACO INC. P.O. Box 1441 MINNEAPOLIS, MN 55440–1441
1530
COPYRIGHT 1991, GRACO INC.
308–537
Rev B
Supersedes A
2340
