- Page 1 19 inch TFT LCD Monitor iC194 USER’S MANUAL...
- Page 2 User’s Manual Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 User’s Manual Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
-
Page 4: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ................... 5 PRECAUTIONS ..................5 SPECIAL NOTES ON LCD MONITORS ........... 6 BEFORE YOU OPERATE THE MONITOR ............ 7 FEATURES ....................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 INSTALLATION INSTRUCTIONS ............. 8 POWER...................... -
Page 5: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 6: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. • Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. •... -
Page 7: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES • 19” TFT Color LCD Monitor • Crisp, Clear Display for Windows • Recommended Resolutions: 1280 X 1024 @75Hz ® • EPA ENERGY STAR • Ergonomic Design • Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: LCD Monitor... -
Page 8: Installation Instructions
User’s Manual INSTALLATION INSTRUCTIONS Install Remove Figure.1. Installing and Removing the Base INSTALLATION: 1. Align the monitor with the opening in the base. 2. Note that the longer section of the base points forward. 3. Snap the monitor into its base. A clear click sound will affirm that the base is connected correctly. -
Page 9: Making Connections
User’s Manual MAKING CONNECTIONS CONNECTING TO A PC: Turn off your computer before performing the procedure below. 1. Connect one end of the D-Sub cable to the back of the monitor and connect the other end to the computer’s D-Sub port. 2. -
Page 10: Adjusting The Viewing Angle
User’s Manual ADJUSTING THE VIEWING ANGLE • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the stand so you do not topple the monitor when you change the monitor’s angle. •... -
Page 11: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 12: Front Panel Control
User’s Manual FRONT PANEL CONTROL • Power Button: Press this button to switch ON/OFF of monitor’s power. • Power Indicator: Green — Power On mode. Orange — Power Saving mode. • MENU / ENTER: 1. Activates the OSD menu or confirms adjustments to settings. 2. -
Page 13: How To Adjust A Setting
User’s Manual HOW TO ADJUST A SETTING iC194A iC194D FUNCTION DESCRIPTION Select the Brightness option on the Main Menu . Enter the option by Brightness pressing the Menu button again, and adjust the level. Select the Contrast option on the Main Menu . Enter the option by Contrast pressing the Menu... - Page 14 User’s Manual Select the V-position option to shift the screen image up or down. V-position Enter the option and adjust the level. Select the Clock Adjustment option to reduce the vertical flicker of Clock Adjustment characters on the screen. Enter the option and adjust the level. Select the Phase Adjustment option to reduce the horizontal flicker of Phase Adjustment...
- Page 15 User’s Manual Select the OSD Transparency option to adjust the transparency of the Transparency OSD. Enter the option and adjust the level. OSD Color Select the OSD Color setting option to adjust the color of the OSD. Enter the option and adjust the level. Language Select the Language...
-
Page 16: Plug And Play
User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bidirectional data channel based on the I²C protocol. -
Page 17: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position Power LED is not on *Power Cord should be connected *Check if the PC system is Plug & Play compatible *Check if the Video Card is Plug &... -
Page 18: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED : 1. Check that the signal-cable is properly connected, If the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. -
Page 19: Appendix
User’s Manual APPENDIX SPECIFICATIONS Driving system TFT Color LCD LCD Panel Size 48.2cm(19.0") Pixel pitch 0.294mm(H) x 0.294mm(V) Video H-Frequency 31KHz – 80KHz V-Frequency 55– 75Hz Display Colors 16.2M Colors Max. Resolution 1280 x 1024 @75Hz VESA DDC2B Plug & Play ON Mode EPA ENERGY Power Saving Mode...
