Summary of Contents for I-Inc iH-252HPB
- Page 1 iH252 HSG 1064...
- Page 2 User’s Manual Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 3: Table Of Contents
SAFETY NOTICE ... 4 PRECAUTIONS... 4 SPECIAL NOTES ON LCD MONITORS ... 5 BEFORE YOU OPERATE THE MONITOR ... 6 FEATURES... 6 CHECKING THE CONTENTS OF THE PACKAGE ... 6 POWER... 7 MAKING CONNECTIONS... 7 ADJUSTING THE VIEWING ANGLE... 9 OPERATING INSTRUCTIONS ... -
Page 4: Safety Notice
• swimming pool or in a wet basement. Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a • person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. -
Page 5: Special Notes On Lcd Monitors
SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the • Power Switch and then turn it on again to make sure the flicker disappears. -
Page 6: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 25” Wide screen TFT Color LCD Monitor • Crisp, Clear Display for Windows • Recommended Resolutions: 1920 X 1080 @60Hz • ® EPA ENERGY STAR • GP Green Product • Ergonomic Design •... -
Page 7: Power
CONNECTING TO A PC Turn off your computer before performing the procedure below. 1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the computer’s D-Sub port. 2. Connect one end of the HDMI to DVI cable (optional) to the back of the monitor and connect the other end to the computer's DVI-D port. - Page 8 User’s Manual Power AC Input HDMI Input Audio Input Figure.1. Connecting to a PC HDMI Input VGA Input Earphone...
-
Page 9: Adjusting The Viewing Angle
ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor, then adjust the • monitor’s angle to your own preference. Hold the stand so you do not topple the monitor when you change the monitor’s angle. -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 3). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 11: Front Panel Control
FRONT PANEL CONTROL Power Button: • Press this button to switch ON/OFF of monitor’s power. Power Indicator: • Green — Power On mode. Orange — Power Saving mode. MENU / RETURN: • 1. Turn the OSD menu on/off or return to the previous menu. - Page 12 ** The screen resolutions available will depend on the purchased model. NOTES: Do not install the monitor in a location near heat sources such as radiators or air dusts, or in a • place subject to direct sunlight, or excessive dust or mechanical vibration or shock.
-
Page 13: How To Adjust A Settings
HOW TO ADJUST A SETTINGS BRIGHTNESS/ CONTRAST BRIGHTNESS CONTRAST X-CONTRAST INPUT SETTING INPUT SETTING AUTO SEARCH COLOR SETTING WARM NATURE (6500K) COOL USER IMAGE SETTING AUTO ADJUST ASPECT RATIO Adjust the brightness value of the display according to your preference. Select「BRIGHTNESS」option to adjust the brightness value. - Page 14 User’s Manual H-POSITION V-POSITION CLOCK PHASE SHARPNESS VIDEO MODE RESPONSE TIME OSD SETTING LANGUAGE H-POSITION V-POSITION TRANSPARENCY OSD TIME-OUT Select the 「H-POSITION」 option to shift the screen image to the left or right. Enter the option and adjust the level. only] Select the 「V-POSITION」...
- Page 15 AUDIO INPUT to HDMI; if no sound is outputted, it is recommended to select AUDIO INPUT as PC, and make sure the PC audio output cable is connected to monitor’s LINE IN (or AUDIO IN) port. [For HDMI Input only] Select the 「VOLUME」...
-
Page 16: Plug And Play
This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bidirectional data channel based on the I²C protocol. -
Page 17: Technical Support (Faq)
LINE IN port (or AUDIO IN port). *Make sure the sound volume adjustment can be clearly identified. *Make sure the System > Silence option in the monitor menu is on. *While transferring via HDMI port but no sound is outputted, it is recommended to select AUDIO User’s Manual... - Page 18 User’s Manual INPUT as a PC option, and make sure PC audio output cable is connected to monitor’s LINE IN port(or AUDIO IN port). [For HDMI Input only]...
-
Page 19: Error Message & Possible Solutions
ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED : 1. Check that the signal-cable is properly connected, If the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. - Page 20 1440×900 @60Hz 1440×900 @60Hz 1440×900 @75Hz 1600×1200 @60Hz 1680×1050 @60Hz 1920×1080 @60Hz 1920×1080 @60Hz ** We ensure that the monitor can be lighted under interlace signal mode, but we can not guarantee the image quality. 74.592 63.981 76.020 79.976 47.712 64.744...
-
Page 21: Appendix
APPENDIX SPECIFICATIONS LCD Panel Video Display Colors Max. Resolution Plug & Play Power consumption Audio output Input Terminal Maximum Screen Size Power Source Environmental Considerations Dimensions Weight (NW) *** The above specification is subject to actual product specification and is subject to change without prior notice.
