American Standard Rondo Whirlpool 7242.028W Specifications

RONDO WHIRLPOOL
7242.028W Whirlpool featuring System II
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• Two person design with center drain and dual
lumbar ends
• Wave style grab bar
• 2.0 HP, two speed, self-draining pump/motor
with pulse feature
• Factory installed power cord and plug
• Ten multi-directional and flow-adjustable jets
including:
- Two Ideal-flow jets
- Six body massage jets
- Two recessed back-rest jets
• Deck-mounted electronic control with 20
minute built-in timed safety shut off and
Chrome Bezel
• Three silent air volume controls
• Quick Connect Safe-T-Heater connection
system
• Factory installed and tested whirlpool system
7242.028WC StayClean™ Whirlpool
Massage featuring System II
• Same as 7242.028W except with the
StayClean™ whirlpool system featuring
Antimicrobial AlphaSan®
Nominal Dimensions: 1816 x 1067 x 546mm
(71-1/2" x 42" x 21-1/2")
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Rev. 3/03
To Be Specified - Required:
Color:
Bath Filler: (specify finish)
Symphony Drain: 1573.272 (specify color)
Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
Safe-T-Heater*: 9075.120
Universal Tile Bead Kit: 751755-100
Twist Syle Grab Bar: 750565-000 (specify color)
System II Control Bezel: 9861.100 (specify finish)
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.
© 2003 American Standard Inc.
RONDO™ WHIRLPOOL
HIGH GLOSS ACRYLIC
or
BV-10
