RONDO ELITE™ WHIRLPOOL
Comfortable two person oval design with dual
back support positions and factory installed
grab bar
7242E (specify White 020, Bone 021, or
Linen 222)
• Acrylic with fiberglass reinforcement
• 2.0 HP self-draining pump/motor
with dry run seal
• Ten multi-directional and flow adjustable jets
including:
Two high performance Ideal-flow™ Jets
Eight interchangeable Flex-jets™
• Three silent air volume controls
• Deck-mounted On/Off control
• Complete factory installed and tested
whirlpool system
7242EC (specify White 020, Bone 021, or
Linen 222)
• Same as above with the StayClean™
whirlpool system featuring Antimicrobial
AlphaSan®
Nominal Dimensions: 1816 x 1067 x 546mm
(71-1/2" x 42" x 21-1/2")
Components Needed:
Bath Filler*: (specify finish)
Bath Drain: BATH-DRAIN
(specify Chrome 002, Polished Brass 099,
or Satin 295)
Custom Accessories Available:
Pulse Jet Kit: PULSE-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
Soft Jet Kit: SOFT-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
E-Z-Install™ Whirlpool Heater - EZHEAT-100
* See American Standard Faucet Selector
Revised 6/03
WHIRLPOOLS BY AMERICAN STANDARD
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
NOTE: Roughing-in dimensions and product specifica-
tions shown on reverse side of page.
NOTE: E-Z-Install™ Whirlpool Heater is designed to
maintain water temperature during operation. It will not
heat cold water to desired bathing temperature.
SPS 7242E
© 2003 American Standard Inc.
RONDO ELITE™
HIGH GLOSS ACRYLIC
HD-006
