American Standard Savona Corner 752857-007OA Parts List

FLEX JET
ESCUTCHEON
ASSEMBLY
AIR ACTUATOR
CAP AND BODY
DISCHARGE
TEE
PUMP
Pump Suction Coupling
O-Ring
Pump Discharge Coupling
Pump w/Air Switch (2.1 H.P.)
Silent Air Control Valve
Flex Jet Nozzle Assembly
Flex Jet Escutcheon Assembly
Flex Jet Body Assembly
Idealflow Nozzle Assembly
Idealflow Escutcheon Assembly
Idealflow Body Assembly
Suction Guard
Suction Fitting
Suction Fitting Elbow
Discharge Tee
Safety Suction Device 8 lb.
Air Acutator Cap & Body
Air Switch
Air Actuator Tubing
NOTE: Schedule 40 Rigid PVC Piping available through local plumbing supply outlets.
Replace XXX with Fixture Color Code, YYY with Trim Finish
Removal/installation requires tool part no. 752905-0070A
Removal/installation requires tool part no. 752906-0070A
1" RIGID
PVC TUBING
FLEX JET
BODY
ASSEMBLY
FLEX JET
JET NOZZLE
ASSEMBLY
HEATER
AIR CONTROL
BLANK
O-RING
PUMP
DISCHARGE
SAFETY
COUPLING
SUCTION
DEVICE
O-RING
PUMP
SUCTION
COUPLING
DESCRIPTION
IDEALFLOW
JET
IDEALFLOW
SILENT
ESCUTCHEON
ASSEMBLY
VALVE
1/2" RIGID
PVC TUBING
SUCTION
GUARD
1-1/2" RIGID
PVC TUBING
Replace XXX with
Fixture Color Code,
YYY with Trim Finish
PART NUMBER
047186-0070A
047187-0070A
047186-0070A
752857-007OA
752855-XXX0A
752851-XXX0A
752850-XXX0A
752849-0070A
752407-XXX0A
752408-XXX0A
752409-0070A
750537-XXX0A
752396-XXX0A
751186-0070A
047438-0070A
752205-1000A
752439-YYY0A
752388-0070A
047602-0070A
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
© A m e r i c a n S t a n d a r d I n c . 2 0 0 1
SAVONA CORNER
ELITE WHIRLPOOL
Model No. 2902E
IDEALFLOW
NOZZLE
ASSEMBLY
IDEALFLOW
BODY
ASSEMBLY
LUMBAR
JETS
1" RIGID
PVC TUBING
IDEALFLOW
JET
SUCTION
FITTING
SUCTION
FITTING ELBOW
PKG QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3 Ft.
