Gefen EXT-VGA-142N User Manual

1:2 vga hub
Hide thumbs Also See for EXT-VGA-142N:

Advertisement

Quick Links

Download this manual
1:2 VGA Hub
EXT-VGA-142N
User Manual
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w.gefen.com
®

Advertisement

loading

Related Manuals for Gefen EXT-VGA-142N

Summary of Contents for Gefen EXT-VGA-142N

  • Page 1 ® 1:2 VGA Hub EXT-VGA-142N User Manual w.gefen.com...
  • Page 3 Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 1:2 VGA Hub is a trademark of Gefen, LLC All trademarks are the property of their respective companies.

  • Page 4: Table Of Contents

    CONTENTS Introduction Operation Notes Features Panel Layout Panel Descriptions Connecting the 1:2 VGA Hub Wiring Diagram Specifi cations Warranty...

  • Page 5: Introduction

    Congratulations on your purchase of the 1:2 VGA Hub. Your complete satisfaction is very important to us. Gefen Gefen delivers innovative, progressive computer and electronics add-on solutions that harness integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products supplement cross-platform computer systems, professional audio/video environments and HDTV systems of all sizes with hard-working solutions that are easy to implement and simple to operate.

  • Page 6: Operation Notes

    OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE PROFESSIONAL AUTOMATION CONTROL SYSTEM • By default, display information (EDID) from the display connected to the Monitor 1 port on the 1:2 VGA Hub is sent back to the source. The VGA display connected to the Monitor 2 port must be capable of accepting the same timings and resolutions as the display that is connected to the Monitor 1 output port.

  • Page 7: Features

    FEATURES Features • Connects computers with VGA graphics to two VGA compatible monitors • Allows two VGA displays to be connected at the same time to the same video • Simultaneously display at local and remote locations • Maintains highest video resolutions up to 1920 x 1200 and 1080p Full HD •...

  • Page 8: Panel Layout

    PANEL LAYOUT Front Back...

  • Page 9: Panel Descriptions

    PANEL DESCRIPTIONS Power This LED indicator glows bright red when the included power supply is attached and connected to an AC electrical outlet. 5V DC Connect the included power supply to this power receptacle. VGA In Connect the included VGA cable between the VGA In port on the 1:2 VGA Hub and the computer.

  • Page 10: Wiring Diagram

    Monitor 1 output port. Therefore, it is recommended that the display with the lowest native resolution be connected to the Monitor 1 port. Wiring Diagram for the 1:2 VGA Hub VGA CABLE Computer Splitter Monitor Monitor EXT-VGA-142N...

  • Page 11: Specifi Cations

    SPECIFICATIONS Video Amplifi er Bandwidth ............... 350 MHz Input Video Signal ................1.2 volts p-p Maximum Resolution ................1920 x 1200 Power Consumption ................ 5 Watts (max.) Power Supply ....................5V DC Dimensions ................2.6”W x 1.1”H x 2.6”D Shipping Weight ..................... 2 lbs...

  • Page 12: Warranty

    Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
  • Page 14 Rev A 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL listed power supplies.
