10.4" Multi-Color LCD RADAR
MODEL 1937
SPECIFICATIONS OF MODEL 1937
ANTENNA RADIATOR
Type
Slotted waveguide array
Antenna Length and Rotation Speed
Open 120 cm (XN12A) 48 RPM
Wind Load
70 kn relative wind
Beamwidth
Hor. 1.9°, Vert. 22°
RF TRANSCEIVER
Frequency
9410 ± 30 MHz (X-band)
Output Power
4 kW
DISPLAY
Screen Size
10.4" color LCD
Pixel Number and Screen Resolution
640 (V) x 480 (H), VGA
Effective Diameter
158 mm
Echo Colors
32 levels
Display Modes
Head-up, Course-up*, North-up*, True
view*, True motion**
* Heading data required
** Heading and position data required
Range Units
nm, sm, km
Range Scales and Range Ring Intervals (nm)
Range:
1/16, 1/8, 1/4, 1/2, 3/4, 1, 1.5, 1.6, 2, 3,
3.2, 4, 6, 8, 12, 16, 24, 32, 36, 48
Rings:
1/32, 1/16, 1/8, 1/4, 1/2, 0.8, 1, 2, 3, 4,
6, 8, 12
Minimum Range
16 m
Range Discrimination
15 m
Echo Trails
Type
True or relative trails
Trail Length:
15, 30 sec., 1, 3, 6, 15, 30 min.,
or continuous Trail
Trail Width:
Narrow, Normal
Plotting Facilities (Required optional board ARP-11)
Acquisition:
Auto, Manual
Number of Targets:
10 targets max.
Display Unit (RDP-152)
17
5.4 kg 11.9 lb
0.7"
129 5.1"
323 12.7"
22 0.9"
310 12.2"
62 2.4"
169
25
Antenna Unit (XN12A)
6.7"
1.0"
25 kg 55.1 lb
1255 49.4"
Fixing holes
250 9.8"
250 9.8"
Cable entry
213 8.4"
25
357 14.1"
438 17.2"
340 13.4"
200 7.9"
FURUNO SVERIGE AB
FURUNO ELECTRIC CO., LTD.
FURUNO ESPAÑA S.A.
Västra Frölunda, Sweden
Nishinomiya, Hyogo, Japan
Madrid, Spain
www.furuno.co.jp
www.furuno.es
www.furuno.se
FURUNO U.S.A., INC.
FURUNO DANMARK AS
FURUNO FINLAND OY
Camas, Washington, U.S.A.
Hvidovre, Denmark
Espoo, Finland
www.furuno.fi
www.furunousa.com
www.furuno.dk
FURUNO (UK) LIMITED
FURUNO NORGE A/S
FURUNO POLSKA Sp. Z o.o.
Havant, Hampshire, U.K.
Ålesund, Norway
Gdynia, Poland
www.furuno.pl
www.furuno.co.uk
www.furuno.no
FURUNO FRANCE S.A.S.
Bordeaux-Mérignac, France
www.furuno.fr
AIS Functions (Data input from AIS is required)
Symbols:
Sleeping, Activated, Dangerous,
Selected, Lost targets
Number of Targets:
100 targets max.
INTERFACE
Input
AD-10 or IEC 61162 NMEA0183
Ver. 1.5/2.0/3.0
Output
IEC 61162 NMEA0183 Ver. 1.5/2.0/3.0
ENVIRONMENT
Temperature
Antenna Unit:
-25°C to +55°C (-13°F to +131°F)
Display Unit:
-15°C to +55°C (5°F to +131°F)
Waterproofing
Antenna Unit:
IEC60529 IP26
Display Unit:
IEC60529 IP55
POWER SUPPLY
12-24 VDC: 8.1-3.8 A
EQUIPMENT LIST
Standard
1. Display Unit
2. Antenna Unit
3. Antenna Cable
5, 10, 15, 20 or 30 m
4. Power Cable
5 m
5. Installation Materials and Spare Parts
Option
1. Auto Plotter
ARP-11
2. Rectifier
RU-3423
3. External Alarm Buzzer OP03-21
4. Interface Cable
MJ-B24LPF0010
10, 20, or 30 m
MJ-A7SPF0007-050C 5 m
MJ-A6SPF0007-100C 10 m
MJ-A10SPFW0001+R 0.2 m
INTERCONNECTION DIAGRAM
Antenna Unit
MJ-A6SPF0007-100C
MJ-B24LPF0005
5/10/15/20/30 m
Gyro Converter AD-100
MJ-A7SPF0007-050C
Display Unit
MJ-A7SPF0007-050C
ARP-11
MJ-A10SPFW
MJ-A7SPF
0001+R
0007-050C
MJ-B24
LPF-0010
Rectifier
BOW
*For further info, contact our depot
12-24 VDC
100/110/115/
220/230VAC
4- 15
All brand and product names are registered trademarks, trademarks
or service marks of their respective holders.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
09063U Printed in Japan
FURUNO DEUTSCHLAND GmbH
Rellingen, Germany
www.furuno.de
FURUNO EURUS LLC
St. Petersburg, Russian Federation
www.furuno.com.ru
FURUNO HELLAS LTD.
Piraeus, Greece
10.4" Multi-Color LCD RADAR
High performance radar for river use
High performance radar for river use
1 unit
1 unit
1 pc
1 pc.
1 set
Satellite Compass
SC-30*/50/110
Heading Sensor
PG-500
Gyrocompass
GPS Navigator, AIS
Sounding Equipment
GPS Navigator, AIS
Sounding Equipment
External Alarm Buzzer
Remote Display*
Option or local supply
Catalogue No. R-197
MODEL 1937
and high-speed craft
and high-speed craft
www.furuno.com
