Specifications - Gallien-Krueger Backline 115 Owner's Manual

Block Diagram: Backline 115 & 250BL
Backline 115 & 250BL Specifications:
Output Power:
125W Amplifier
Input Section:
Maximum Input Level
With -10dB pad
Input Impedance
Send output impedance
Return input impedance
Tuner Output Impedance
Direct Output Impedance
Equalizer:
Bass +10db @ 60Hz
Lo-Mid +6db/-10dB @ 250Hz
Hi-Mid +6db/-10dB @ 1kHz
Treble +14db @ 7kHz
Contour +2db@50Hz/
-10db@500Hz/
+3db@7kHz
Noise -90db referenced to 125W,
"A" weighted
Amplifier Protection: Full short circuit, thermal,&
RF protection.
Stable into reactive and
mismatched loads.
Five second muted warm-up.
Backline Series Backline Series
Backline Series Backline Series Backline Series
125W @ 8 Ohms
0.6V Rms
1.6V Rms
1M Ohm
220 Ohm
60k Ohm
10k Ohm
1000 Ohms
15
Power Requirements:
U.S.A./Canada 120V/60Hz
228W (at fullpower)
89W (at average power)
Europe 230V/50Hz
228W (at fullpower)
89W (at average power)
Japan 100V/50Hz
228W (at fullpower)
89W (at average power)
Dimensions(HxWxD):
Backline 250BL: 3 1/2" x 17" x 8 ¼"
(2 Rack Spaces)
Backline 115: 22"x19"x18"
Weight:
Backline 250BL: 12lbs
Backline 115: 60lbs
