Summary of Contents for Gallien-Krueger Backline 210
- Page 1 Backline 350 & 210 Owner’s Manual Backline 350 Backline 210...
- Page 3 For our part, we at Gallien-Krueger are pleased that you chose us, and are determined that you dealer, or us as soon as possible at: will be a satisfied customer.
- Page 4 I have never seen the point in doing things the way others have done them. I also have not been very interested in following the latest fad. I am a Stanford educated engineer who worked his way through school as a musician. Like all musicians, I have lugged amplifiers up stairways and into car trunks, always wondering why these things had to be so heavy, bulky, and hard to handle.
- Page 5 To avoid safety hazards, use only the power cord supplied with your unit. If a replacement cord is used, make Your new Backline unit has been factory certain that it is of consistent quality and gauge as the configured for use with: original.
- Page 6 Your Backline unit is designed to be simple to operate. All controls have a well defined purpose and are well behaved. You should be hearing your bass quite well. You can use These directions will take you through the basics and give the volume and Master to achieve a comfortable sound you a good start for setting up your sound.
- Page 7 The Backline 350/210 is versatile in its sound and tone. Below are a few suggested amp settings that can be used as starting points to define your own sound. Note: the Gain/Overdrive settings will vary according to the output of your bass. * Contour note: At higher playing levels the contour should be set lower for mid-range clarity.
- Page 8 The Backline Series has several unique features which, if used properly, will obtain that sound you have been searching for. The Equalizer is used to fine tune your sound. When The Backline 350/210 provides a low noise, high adjusting it, do it a little at a time. These are active quality balanced direct out for connection to PA and recording consoles.
- Page 9 A standard ¼" input jack and input attenuator button. ¼" jack for a standard single pole latching foot switch. The button is generally left out, except in rare cases when It Switches from channel “A” to “B”. The “A/B” switch the clip LED flashes or distortion occurs at low volume must be out for this function to operate.
- Page 11 To insure proper operation and to avoid When the unit gets dirty, clean only with a dry cloth. potential safety hazards, place the unit on a Never use benzene, thinner, alcohol, or other volatile firm, level surface. When installing the unit cleaning agents.
- Page 12 Backline 210: Two 8 Ohm 10" speaker The Backline 210 combo electronics are identical to the Backline 350 head and are rated for the same maximum power output and speaker load (175W into 4 Ohms). To drive an external cabinet, the combo’s internal speaker can be disconnected by unplugging the speaker cable connected to the combo’s back panel.
- Page 13 The equalization in the power light changes from Green to Red. The amplifier Gallien-Krueger amplifiers reflects 30 years of continuous will remain muted until the fault is removed. If the development and refinement. The GK equalizer is unique protection circuit activates while playing, turn the to the industry, it’s not just a normal four band equalizer,...
- Page 14 Output Power: 175W @ 4 Ohms Power Requirements: 115W @ 8 Ohms Input Section: U.S.A./Canada 120V/60Hz Maximum Input Level 0.6V Rms 325W (at fullpower) With -10dB pad 1.6V Rms 108W (at average power) Input Impedance 1M Ohm Europe 230V/50Hz Send output impedance 220 Ohm 325W (at fullpower) Return input impedance...
- Page 16 Backline 350/210 Owner’s Manual Part # 160-0270-A Printed in the U.S.A.
