- Page 1 USER GUIDE BP-100...
- Page 2 Welcome Thank you for making Fishman a part of your acoustic experience. We are proud to offer you the fi nest acoustic amplifi cation products available: high-quality professional-grade tools which empower you to sound your very best.
-
Page 3: Troubleshooting
Troubleshooting If you are unfamiliar with this product, please pay close attention to the requirements for installation. Failure to do so can result in permanent damage to the pickup. Installation by a qualifi ed professional is strongly recommended. Technical support, troubleshooting tips and installation information can be found at http://www.fi... -
Page 4: Installation
Installation FELT-COVERED SPRING CLIP Prepare the bridge 1. The area of the bridge where the elements will be mounted must be fl attened with a sanding block or a fl at fi le. Otherwise, the SENSING performance of the pickup will be adversely ELEMENT affected. - Page 5 Mount the pickup Caution: do not pull or bend the wires at the bases of the elements. You may destroy the pickup! 1. Slide the pickup wire through the E-string side wing slot. OUTPUT 2. Center the elements black side up on the side of WIRE the bridge that faces the fi...
-
Page 6: Fine Tuning
Fine Tuning • Mounting the elements ¼” to ½” below the top edge of the bridge will produce a different sound. • You may fi ne tune the string balance by moving the upper corner of an element closer to or further from an individual string. •... - Page 7 Plugging In An impedance matching preamp is recommended, but not required. This will help realize the full frequency response potential of the pickup and allow for cable runs longer than 10 feet without signal deterioration. Use a high quality, low capacitance ¼” shielded instrument cable. This will ensure minimal tone coloration and hum.
- Page 8 WWW.FISHMAN.COM 009-015-001 Rev C 4-09...
