  • Page 1 USER GUIDE fishman.com SA SUB...

  • Page 2: Important Safety Instructions

    The mains plug/appliance coupler is used as disconnect device, the disconnect device shall remain readily operable. Copyright © 2016 FISHMAN TRANSDUCERS, INC. All rights reserved. No part of this document may be reproduced in any form without the written permission of FISHMAN TRANSDUCERS, INC.
  • Page 3 NOTE: Fishman Transducers, Inc. is not responsible for unauthorized equipment modifications that could violate FCC rules, and/ or void product safety certifications. EU Declaration of Conformity CE: Hereby, Fishman declares that this SA Sub is in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EU, 2014/35/EU. The...
  • Page 4 “boomy” sound from rooms or program material that over- emphasize the lowest octaves. 7. Volume –This control sets the overall level of the SA Sub. It’s a good practice to match the level of the SA Sub with SA330x (or other amplifier system), then use the master volume on the SA330x to adjust the overall system volume.
  • Page 5 Sub’s set to opposite Phase in the same room will tend to cancel each other in most locations, and should be avoided. 9. Front LED – SA Sub has a Power indicator on both the front and back for convenient viewing. In cases where the Front LED may be distracting, it can be turned Off by setting the switch to that position.

  • Page 6: Block Diagram

    Block Diagram LEFT INPUT LEFT OUTPUT (XLR + 1/4”) (XLR) CROSSOVER SUBSONIC VOLUME LIMITER PHASE 300W AMP LOW PASS FILTER EXTENSION FILTER 80/100/125Hz 0º / 180º SIGNAL / LIMIT LED RIGHT INPUT RIGHT OUTPUT (XLR + 1/4”) (XLR)

  • Page 7: Technical Specifications

    Technical Specifications Input Impedance: 1/4” Input 20k Ohm unbalanced 40k Ohm balanced XLR Input 40k Ohm balanced Full Range Output: Direct Pass Through Switchable ground lift Speaker System: Driver 8” custom-designed woofer, ferrite magnet Amplifier: Woofers 300W rms; 600W peak Frequency Response 30Hz –...
  • Page 8 Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 513-300-231_r1 7/16...
