- Page 1 U s e r G u i d e U s e r G u i d e Outboard Acoustic Preamps Includes Instructions for Model GII General Purpose Preamp Model BII Acoustic Bass Preamp Pro EQ II Acoustic Instrument Preamp / EQ...
- Page 2 Outboard Acoustic Preamps Outboard Acoustic Preamps Thank you for choosing a Fishman Outboard Acoustic Preamp. Our goal is to provide you with the finest products for amplifying your acoustic instrument - systems that simply let you sound your best. With our long-standing commitment to quality, you can feel confident that your Fishman gear will produce great sound and trouble-free performance for years to come.
- Page 3 U s e r G u i d e U s e r G u i d e Model GII & Model BII Model GII & Model BII The GII and BII are upgraded and updated versions of our classic Model G & B preamps.
- Page 4 2 - 9-Volt AC Adapter Input Use only a Fishman 910-R or Boss PSA series regulated AC adapter. If a 9 Volt battery is in the preamp, no battery drain will occur when you use the AC adapter.
-
Page 5: Tone Controls
U s e r G u i d e U s e r G u i d e If the signal coming from your pickup is very weak, you may wish to turn the input trim clockwise, which will raise the overall level and reduce system noise (hiss). If you hear distortion when you play (with a new battery), lower the input trim until it goes away. - Page 6 Outboard Acoustic Preamps Outboard Acoustic Preamps Optional Belt Clip Attaches to the back of the GII or BII with two screws. GII S ODEL PECIFICATIONS Measured with all tone controls at center detent and volume at max. Nominal Input Level: -20 dBV Input Overload (20 Hz to 20 kHz): +8 dBV...
- Page 7 U s e r G u i d e U s e r G u i d e BII S ODEL PECIFICATIONS Measured with all tone controls at center detent and volume at max. Nominal Input Level: -20 dBV Input Overload (20 Hz to 20 kHz): +8 dBV Input Impedance: 10 MOhm...
- Page 8 Outboard Acoustic Preamps Outboard Acoustic Preamps Pro EQ II Pro EQ II The Pro EQ II is an upgraded and updated version of our classic preamp/equalizer. It is well suited for all acoustic instrument pickups. Enclosed in a tough injection molded case, the Pro EQ II features advanced new electronics which are quieter, cleaner and offer longer battery life than our original Pro EQ preamp.
-
Page 9: Input Gain
2 - Nine-Volt AC Adapter Input Use only a Fishman 910-R or Boss PSA series regulated AC adapter. If a 9 Volt battery is in the preamp, no battery drain will occur when you use the AC adapter. - Page 10 Outboard Acoustic Preamps Outboard Acoustic Preamps Input Gain Continued If the signal coming from your pickup is very weak, turn the input gain clockwise to reduce the overall system noise (hiss). If you hear distortion when you play (with a fresh battery), lower the input trim until it goes away.
- Page 11 U s e r G u i d e U s e r G u i d e Volume For the cleanest signal, set this as high as possible without distorting your amp or mixer Optional Belt Clip Attaches to the back of the Pro EQ II with two screws. -EQ II T ONTROLS Bass...
- Page 12 Outboard Acoustic Preamps Outboard Acoustic Preamps EQ S AMPLE ETTINGS Here are a few suggested settings for the Pro EQ II: Finger Style This setting will add fullness to the bass and definition to the treble.
- Page 13 U s e r G u i d e U s e r G u i d e "Scooped" Mid This is the popular "smiley eq " tone that emphasizes extreme bass and treble. Strummer This is a good overall setting if you mainly strum the instrument.
- Page 14 Outboard Acoustic Preamps Outboard Acoustic Preamps Sample Settings Continued Cut through the mix This setting is helpful when you need to be heard through a loud band.
- Page 15 U s e r G u i d e U s e r G u i d e -EQ II S PECIFICATIONS Measured with all tone controls at center detent and volume at max. Nominal Input Level: -20 dBV Input Overload (20 Hz to 20 kHz) +8 dBV Input Impedance: 10 MOhm...
-
Page 16: Return Policy
L i m i t e d W a r r a n t y FISHMAN Model GII BII and Pro-EQ II Preamps are warranted to function for a period of One (1) Year from the date of purchase. If the unit fails to function properly within the warranty period, free repair and the option of replacement or refund in the event that FISHMAN is unable to make repair are FISHMAN’s only...
