GHOST System Overview
Optional
QuickSwitch
(PE-0111-00)
Optional
Push/Push Volume Pot
or MidBoost Switch
(PE-0206-00 or
PE-0106-00)
Magnetic In
(GREEN)
Stereo Jack
IMPORTANT!
is an artistic representation
only,
not
a
Consult this guide for correct
wiring procedure to avoid
voiding your warranty.
4
Power/Battery
This diagram
schematic.
Common
Connector Block
(BE-5017-00)
