Do you have a question about the 2105M and is the answer not in the manual?

Questions and answers

Andy Green

May 23, 2025

Engine struggles to start, when it does it just ticks over with black smoke, when you engage the cutting blades the engine stops !

1 comments:

Mr. Anderson

May 25, 2025

A Mountfield 2105M engine that struggles to start, produces black smoke, and stops when engaging the cutting blades could have the following issues:

1. Air-Fuel Mixture Problems: Black smoke suggests the engine is running too rich (too much fuel, not enough air), possibly due to a dirty air filter or carburetor issues.

2. Choke Left On: If the choke remains engaged after starting, it can cause rich running and black smoke.

3. Spark Plug Fault: A fouled or improperly connected spark plug can cause poor starting and weak engine performance.

4. Power Take-Off (PTO) Safety System Fault: If the engine stops when engaging the blades, the PTO safety switch or related safety system may not be working properly.

5. Low Oil Level: If oil is low, especially when on slopes, the engine may stop to prevent damage.

6. Obstruction or Load on Blades: Engaging blades with debris or resistance may overload and stall the engine.

Check and clean the air filter, inspect the spark plug, ensure the choke is disengaged after starting, verify oil level, and inspect the PTO safety system.

This answer is automatically generated

Summary of Contents for Mountfield 2105M

Page 1 2105M - 2125H BRUKSANVISNING ISTRUZIONI PER L’USO KÄYTTÖOHJEET INSTRUCCIONES DE USO BRUGSANVISNING INSTRUÇõES DE UTILIZAÇÃO BRUKSANVISNING INSTRUKCJA OBS£UGI GEBRAUCHSANWEISUNG »HC“P”K÷»ﬂ œOÀ‹«Œ¬¿“EÀﬂ INSTRUCTIONS FOR USE NÁVOD K POU®ITÍ MODE D’EMPLOI HASZNÁLATI UTASÍTÁS GEBRUIKSAANWIJZING NAVODILA ZA UPORABO 8211-0411-01...
Page 2 SVENSKA D, E...
Page 3 SVENSKA...
Page 4 SVENSKA 0,7 - 0,8 mm...
Page 5: Safety Instructions
Do not wear loose, hanging clothes, This machine is available in two versions. jewellery, scarves, ties, etc., which can get • manual transmission, designated 2105M. caught in rotating parts. Tie up long hair. • hydrostatic transmission, designated 2125H. • Carefully check the area that is to be cut/cleared of snow.
Page 6 ENGLISH b. Only fill or top up with petrol outdoors, and both before and during reversing to check for never smoke when filling or topping up. any obstacles. Look out for small children. c. Fill with petrol before starting the motor. •...
Page 7: Maintenance And Storage
ENGLISH place. c. Before adjusting the height setting, assuming this cannot be done from the driver’s position. • Existing safety devices may not be disconnected or disengaged. Check that the • Reduce the acceleration when the engine is to safety devices work each time before using the be stopped, and if the engine is equipped with a machine.
Page 8: Accessories Bag
ENGLISH position, the cutting deck must be lowered ASSEMBLY when parked, stored or when the machine is left unsupervised. To avoid injury and damage to people • If the petrol tank is to be emptied, this must take and property, do not use the machine place outdoors.
Page 9: Steering Wheel
ENGLISH tenance free. You don’t have to check or top up the In the rear holes, the screws G should be used electrolyte level. along with the shoulder washers F. Tighten the screws. On delivery, the battery is in the accessories box. Then place the wing nuts H with the two screws G The battery must be fully charged be- and washers I in the front holes.
Page 10: Controls And Instruments
– the machine moves forwards. 2A. SERVICE BRAKE/CLUTCH 2. No load on the pedal – the ma- (2105M) chine is stationary. A pedal that combines both service brake and 3. Depress the pedal with your clutch. There are 3 positions: heel –...
Page 11: Areas Of Use
500 N. ating position 2/3. NOTE! This machine is not intended to be driven 7. GEAR LEVER (2105M) on public roads. A lever for selecting one of the five forward gears in the gearbox (1-2-3-4-5), neutral (N) or reverse STARTING AND OPERATION (R).
Page 12: Safety System
This will allow the consists of: oil to warm up. - a switch on the gearbox (only 2105M). When in use, always operate the engine at full - a switch on the break pedal (only 2125H).
Page 13: Service And Maintenance
ENGLISH open. Change oil when the engine is warm. Always use a good grade of oil (service grade SF, SG or SH). Never drive with the cutting deck in the raised position. This damages the deck The engine oil may be very hot if it is drive belt.
Page 14: Spark Plug
ENGLISH 5. Assemble in the reverse order. STEERING CABLE Petroleum-based solvents such as kerosene may The steering cables should be adjusted for the first not be used for cleaning the paper filter insert. time after the machine has been in operation for 2 These solvents can destroy the filter.
Page 15: Product Identity
ENGLISH Neither does the guarantee cover: points: - wearing components such as blades, belts, • Always use Alkylate petrol (“Environmental wheels and cables petrol“). - normal wear • Always use a funnel and/or a petrol can with overfill protection to avoid spillage when filling - engine and transmission.
Page 16 EC conformity declaration 1.Category Lawnmower with petrol engine 8.Make Mountfield 2.Type V301 9.Cutting width 1-2. 85 cm 3-4. 92 cm 3.Item no 1. 13-2715 + 13-2940 3. 13-2715 + 13-2929 2. 13-2716 + 13-2940 4. 13-2716 + 13-2929 4.Manufacturer GGP Sweden AB 10.Serial number...
