www.weslo.com
Model No. WLEX31510.3
Serial No.
Write the serial number in the space
above for reference.
Serial Number
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-866-699-3756
Mon.––Fri. 6 a.m.––6 p.m. MT
Sat. 8 a.m.––4 p.m. MT
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Decal
USER’'S MANUAL
Meijer.com
Advertisement
Table of Contents
Related Manuals for Weslo WLEX31510.3
Summary of Contents for Weslo WLEX31510.3
- Page 1 Meijer.com www.weslo.com Model No. WLEX31510.3 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.
-
Page 2: Table Of Contents
If a decal is missing or illegible, see the front cover of this manual and request a free replacement decal. Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
Meijer.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
Meijer.com BEFORE YOU BEGIN Thank you for selecting the new WESLO ® PURSUIT reading this manual, please see the front cover of this CT 2.0 R exercise bike. Cycling is an effective exercise manual. To help us assist you, note the product model for increasing cardiovascular fitness, building endur- number and serial number before contacting us. -
Page 5: Part Identification Chart
Meijer.com PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 6: Assembly
Meijer.com ASSEMBLY •• To hire an authorized service technician to •• In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tools: one Phillips screwdriver •• Assembly requires two persons. one adjustable wrench •• Place all parts in a cleared area and remove the packing materials. - Page 7 Meijer.com 3. Insert the end of the Seat Frame (5) into the Frame (1). Firmly press the Frame Bushing (56) into the Frame (1). Attach the Frame Bushing (56) to the Frame (1) with two M4 x 5mm Self-tapping Screws (40). Tighten the Adjustment Knob (9) into the Frame (1).
- Page 8 Meijer.com 6. Attach the Backrest (60) to the Seat Brackets (14, 15) with four M6 x 35mm Screws (61) and four M6 Washers (32). See step 4. Tighten the two M8 Locknuts (10). 7. Attach the Seat (12) to the Seat Brackets (14, 15) with four M6 x 35mm Screws (61) and four M6 Washers (32).
- Page 9 Meijer.com 8. Have a second person hold the Upright (13) near the Frame (1) until step 9. Connect the Extension Wire (52) to the Reed Wire (43). Then, connect the Resistance Cable (19) to the Lower Resistance Cable (45) in the following way: ••...
- Page 10 Meijer.com 10. Attach the Handlebar (53) to the Upright (13) with two M8 x 65mm Bolts (36), two M8 Curved Washers (46), and two M8 Locknuts (10). 11. The Console (16) requires four AA batteries (not included); alkaline batteries are recommended. Screw Battery Cover Do not use old and new batteries together or...
-
Page 11: How To Use The Exercise Bike
Meijer.com 13. Identify the Left Pedal (24), which is marked with an ““L.”” Using an adjustable wrench, firmly tighten the Left Pedal (24) counterclockwise into the left arm of the Crank (21). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank (not shown). Adjust the strap on the Left Pedal (24) to the desired position, and press the end of the strap onto the tab on the Left Pedal. - Page 12 Meijer.com FEATURES OF THE CONSOLE HOW TO USE THE MANUAL MODE 1. Turn on the console. To turn on the console, press any of the buttons or begin pedaling. The entire display and the pace guide will turn on for a moment; the console will then be ready for use.
- Page 13 Meijer.com When you turn Note: When the batteries are replaced, it may Indicators on the console, be necessary to reselect the desired unit of the scan mode measurement. will be selected automatically. To reset the display, press the On/Reset button. One indicator will appear below To pause the console, stop pedaling.
- Page 14 Meijer.com HOW TO USE A PACE WORKOUT During the work- out, the pace 1. Turn on the console. guide will prompt you to keep your See step 1 on page 12. pedaling speed near the target 2. Select a pace workout. pace for the current segment.
-
Page 15: Maintenance And Troubleshooting
Meijer.com MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike regu- Turn the Resistance Knob (27) to the lowest setting. larly. Replace any worn parts immediately. Then, locate the Reed Switch (43). Turn the Pulley (21) until the Magnet (38) is aligned with the Reed Switch. To clean the exercise bike, use a damp cloth and a Loosen, but do not remove, the M4 x 15mm Self- small amount of mild detergent. -
Page 16: Fcc Information
Meijer.com HOW TO ADJUST THE DRIVE BELT If you can feel the pedals slip while you are pedaling, even when the resistance is at the highest level, the drive belt may need to be adjusted. To adjust the drive belt, you must first remove the right pedal and the right shield as described below. -
Page 17: Exercise Guidelines
Meijer.com EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 18: Part List
Meijer.com PART LIST Model No. WLEX31510.3 R0112A Key No. Qty. Description Key No. Qty. Description Frame M8 x 20mm Screw Front Stabilizer Drive Belt Handlebar Cap M8 x 65mm Bolt Wheel Eddy Mechanism Seat Frame Magnet Rear Stabilizer M5 Curved Washer... -
Page 19: Exploded Drawing
Meijer.com EXPLODED DRAWING Model No. WLEX31510.3 R0112A... -
Page 20: Ordering Replacement Parts
Meijer.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
