MPFHVLP
Mini Pressure Feed Spray Gun
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Maximum Air and Fluid Inlet Pressure: 50 psi (345 kPa, 3.4 bar)
Maximum HVLP Compliant Air Pressure: 40 psi (276 kPa, 2.8 bar)
Part No. 7045 Spray Gun
For pressure feed spraying of automotive colors and clears.
II 2 G
SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441
1-800-742-7731, www.sharpe1.com
309990C, 4/2006
THE SPRAY GUN PEOPLE
FOR PRODUCT INFORMATION CALL:
1-800-742-7731
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sharpe 309990C
Summary of Contents for Sharpe 309990C
- Page 1 Part No. 7045 Spray Gun For pressure feed spraying of automotive colors and clears. II 2 G SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441 1-800-742-7731, www.sharpe1.com 309990C, 4/2006 THE SPRAY GUN PEOPLE FOR PRODUCT INFORMATION CALL: 1-800-742-7731...
- Page 2 This warranty is in lieu of all other warranties, expressed or implied, including warranties of merchantability and fitness for a particular purpose. Some states do not allow the exclusion or limitations of incidental or consequential damages, so the above limitations may not apply to you. WARNING 309990C...
-
Page 3: Operation
See Troubleshooting guide if you experience an irregular pattern. Fluid control knob (7) is factory set for maximum needle trig- ger travel and material flow. To decrease needle/trigger travel and decrease fluid flow, turn knob clockwise. CAUTION 309990C... -
Page 4: Cleaning And Maintenance
2.8 bar) - delivers 10 psi (69 kPa, 0.7 bar) spraying pressure at air cap Wetted Parts: stainless steel, aluminum, brass, L/D polyethylene Air Consumption: 3.5 CFM at 40 psi (276 kPa, 2.8 bar) Spray Gun • 1/4 npsm (R1/4-19) air and fluid inlets • Weight - 8 oz. (227 grams) 309990C... -
Page 5: Troubleshooting
If pattern follows air cap, problem is in air cap. Clean and inspect. If pattern is not corrected, replace air cap. Fill fluid supply. a. Reduce fluid pressure. b. Increase air pressure. c. Hold gun about 6-8 inches (150-200 mm) from surface. Solution 309990C... - Page 6 SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441 4* 4* Ref. Part No. Description Qty. 34811 29040 34808 Parts included in Repair Kit 34835. 1-800-742-7731, www.sharpe1.com 309990C, 4/2006 12b 7 • Fluid Nozzle • Fluid Needle Air Cap Qty.
