D-5-55
Siphon Feed Detail Spray Gun
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Maximum Air Inlet Pressure: 50 psi (345 kPa, 3.4 bar)
Part No. 7030 Spray Gun and 7510 Cup
For siphon feed spraying of automotive colors and clears. Ideal for
touch-up and detail work.
II 2 G
SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441
1-800-742-7731, www.sharpe1.com
309991C, 4/2006
THE SPRAY GUN PEOPLE
FOR PRODUCT INFORMATION CALL:
1-800-742-7731
Advertisement
Related Manuals for Sharpe D-5-55
Summary of Contents for Sharpe D-5-55
- Page 1 Part No. 7030 Spray Gun and 7510 Cup For siphon feed spraying of automotive colors and clears. Ideal for touch-up and detail work. II 2 G SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441 1-800-742-7731, www.sharpe1.com 309991C, 4/2006...
- Page 2 Check hoses, tubes, and couplings daily. Replace worn or damaged parts immediately. 2 Year Limited Warranty Sharpe warrants this product to the original user against defective material or workmanship for a period of 1 year from the date of purchase.
-
Page 3: Operation
If an air adjusting valve is Flush before using the equipment, before changing colors, and desired, use a SHARPE Air Adjusting Valve 24AAV (part when you are done spraying. Use solvent that is compatible with no. -
Page 4: Cleaning And Maintenance
D-5-55 DETAIL SPRAY GUN Cleaning and Maintenance Cleaning Nozzle and Air Cap CAUTION WARNING • Trigger gun whenever you tighten or remove nozzle to avoid damaging needle seat and nozzle. • Do not use metal tools to clean air cap holes as this may Follow Pressure Relief Procedure when you stop spraying scratch them and distort the spray pattern. -
Page 5: Troubleshooting
D-5-55 DETAIL SPRAY GUN Troubleshooting WARNING Follow Pressure Relief Procedure, page 3, before troubleshooting or servicing. Read warnings, page 2. Problem Cause Solution Normal pattern No action necessary Right Dirty or damaged air cap or fluid nozzle. Rotate air cap 180°. - Page 6 Lid with Fluid Tube 29046 Fluid Control Knob 29057 Coupling Nut 29056 Trigger Screw 29058 Nipple Fitting 29055 Trigger 29030 Width Control Assembly Includes items 10a-10d 118749 • Knob SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441 1-800-742-7731, www.sharpe1.com 309991C, 4/2006...
