Cobalt
HVLP Gravity Feed Spray Gun
Compliant Gravity Feed Spray Gun
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Maximum Air Inlet Pressure: 100 psi (0.7 MPa, 7 bar)
Maximum HVLP Compliant Air Pressure: see table below
Includes Cobalt Gravity Feed HVLP or Compliant Spray Gun and 650GC
Aluminum Gravity Cup
II 2 G
Gun Part
Needle/Nozzle
No.
Size (mm)
HVLP Gravity Feed Gun
5812L
1.2
5814L
1.4
5816L
1.6
5815L
1.5
5818L
1.8
5823L
2.3
Compliant Gravity Feed Gun
5712
1.2
5714
1.4
5716
1.6
*
At HVLP compliant air pressure
†
At 50 psi (345 kPa, 3.4 bar) air inlet pressure
SHARPE MANUFACTURING COMPANY • P.O. BOX 1441, MINNEAPOLIS, MN 55440-1441
Air
Maximum HVLP
Consumption
Air Pressure
(CFM)
psi (kPa, bar)
13.9*
50 (345, 3.4)
13.9*
50 (345, 3.4)
13.9*
50 (345, 3.4)
12.5*
40 (276, 2.8)
12.5*
40 (276, 2.8)
12.5*
30 (207, 2.1)
13.8†
13.8†
13.8†
1-800-742-7731, www.sharpe1.com
309999F, 4/2006
THE SPRAY GUN PEOPLE
FOR PRODUCT INFORMATION CALL:
1-800-742-7731
Recommended Usage
Topcoat, high solids, colors and clears
Topcoat, high solids, colors and clears
Topcoat, medium solids, colors and clears
Primer, high solids, sealers
Primer, general purpose
Primer, high viscosity
Topcoat, high solids, colors and clears
Topcoat, high solids, colors and clears
Topcoat, medium solids, colors and clears
