Options - Icom IC-M88 Instruction Manual

D BATTERY PACKS/CASE
• BP-226
battery case
Battery case for 5 × AA (R6) alkaline cells.
• BP-227/BP-227FM/BP-274
Voltage : 7.4 V
Capacity: BP-227/BP-227FM;
1850 mAh (minimum)/1950 mAh (typical)
BP-274;
1800 mAh (minimum)/1900 mAh (typical)
BP-227/BP-227FM/BP-274 must be charged with the supplied BC-
152N or the optional BC-119N/121N.
BP-227FM must be used for the intrinsically safe type.
D CHARGER
• BC-119N
desktop charger
+ BC-145S
ac adapter
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger.
Charging time: Approximately 2 to 2.5 hours
• BC-121N + AD-100
-
multi charger
+ BC-157S
ac adapter
For rapid charging of up to 6 battery packs (six AD-100's are
required) simultaneously. An AC adapter may be supplied
depending on version.
Charging time: Approximately 2 to 2.5 hours.
• BC-152N
desktop charger
Used for regular charging of battery pack. The same as sup-
plied with the transceiver.
Charging time: Approximately 10 hours
-
l i ion battery pack
+ AD-100
charger adapter
(6 pcs.)
charger adapter
+ BC-147S
ac adapter

OPTIONS

D OTHER OPTIONS
• MB-79
belt clip
Exclusive alligator-type belt clip.
• MB-86
swivel belt clip
Swivel type belt clip. The same as supplied with the trans-
ceiver.
• HM-138
-
speaker microphone
Full-sized waterproof (IPX7 waterproof protection) speaker-mi-
crophones including alligator type clip to attach to your shirt or
collar, etc.
Icom optional equipment is designed for optimal perform-
ance when used with this transceiver. We are not respon-
sible for the transceiver being damaged or any accident
caused when using non-Icom optional equipment.
Available or applicable options may differ according to coun-
tries. Ask your authorized dealer for details.
