i WEATHER CHANNEL/WEATHER ALERT INDICATORS
• "WX" appears when the weather channel group is se-
lected. (p. 9)
• "ALT" appears while the weather alert function is acti-
vated.
o BELL INDICATOR
Blinks when an alert tone is received.
!0 DUALWATCH/TRI-WATCH INDICATORS (p. 15)
"DUAL" appears during dualwatch; "TRI" appears during
tri-watch.
!1 SCRAMBLER INDICATOR (Available for I/S version only)
Appears when the optional voice scrambler is activated.
(pp. 11, 21)
!2 DUPLEX INDICATOR
Appears when a duplex channel is selected.
!3 SUB CHANNEL READOUT
• Indicates Channel 16 during priority scan, dualwatch or
tri-watch. (p. 15).
• Indicates the SET mode item while in SET mode.
!4 CHANNEL NUMBER READOUT
• Indicates the selected operating channel number.
• In SET mode, indicates the selected condition.
PANEL DESCRIPTION
!5 CALL CHANNEL INDICATOR (p. 8)
Appears when the call channel is selected.
!6 CHANNEL GROUP INDICATOR (pp. 9, 16)
"U" appears when U.S.A.; "I" appears when Interna-
tional; "C" appears when Canadian; "
LAND channel group is selected.
!7 TRANSMIT POWER INDICATOR (p. 10)
• "LOW" appears when low power is selected.
• "MID" appears when middle power is selected.
• No indication when high power is selected.
