- Page 1 Omega II DMX-255 User Guide Please read these instructions carefully before use World-wide Headquarters: 3000 North 29th Ct. Hollywood, FL 33020 U.S.A. Tel: +1-954-929-1115 Fax: +1-954-929-5560 www.ChauvetLighting.com...
- Page 2 Introduction Congratulations on the purchase of your new CHAUVET lighting effect. We are confident you will enjoy many trouble free hours with this unit. To assist with the care and use of the product we have prepared this short guide.
- Page 3 The Omega II (DMX-255) is a DMX fixture that can be operated with CHAUVET's DMX-6, DMX-40, DMX-50, ShowXpress or any other universal DMX controller. The unit will also work in stand alone mode sound activated. To operate in DMX mode, you must link the units together using a premium quality 3-pin DMX cable in the following configuration.
- Page 4 DMX Channels Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Gobo Level Color Level Strobe Level Level Tilt Level Blackout White None 0-45 Right Down Open 10-19 Color 1 10-19 Gobo/Color 46-115 Left Gobo 1 20-29 Color 2 20-29 Strobe Gobo 2...
- Page 5 This unit has been designed to be hung. It is recommended that, for safety purposes, your lighting effect be properly mounted using a suitable hanging clamp and safety cable. CHAUVET offers a range of items, which are ideal for safe mounting.
