Technical Specifications
Power
AC 120V 60Hz / AC 230V 50Hz
Fuse
20mm Glass 2.5A 250v Fast Blow
Green 4.9 mW laser diode Wavelength 532 nm
Laser diode
Red 4.9 mW laser diode Wavelength 650 nm
Dimensions
340 x 142 x 169 mm
Weight
4 .8kg / 10.56 lbs
User Information (Please complete for your records)
Data Purchased :
/
/
Dealer Stamp :
Streamer Laser
/ 13.39 x 5.59 x 6.65 in
Serial No. :
Model :
Orbiter RG
LGG-2050GR
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
th
3000 North 29
Hollywood, Florida USA 33020
Tel: +1-954-929-1115
Fax: +1-954-929-5560
Ct.,
Advertisement
Table of Contents
Related Manuals for Chauvet Orbiter RG LGG-2050GR
Summary of Contents for Chauvet Orbiter RG LGG-2050GR
-
Page 1: Technical Specifications
Technical Specifications Streamer Laser Power AC 120V 60Hz / AC 230V 50Hz Fuse 20mm Glass 2.5A 250v Fast Blow Green 4.9 mW laser diode Wavelength 532 nm Laser diode Red 4.9 mW laser diode Wavelength 650 nm Dimensions 340 x 142 x 169 mm / 13.39 x 5.59 x 6.65 in Weight 4 .8kg / 10.56 lbs... - Page 2 5. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. If the unit does not work- no light output or fan is not working 1. Check the main power connection and the fuse. 2.
- Page 3 1. Safety Instruction Please read carefully the instruction, which includes important information about the installation, usage and maintenance. WARNING TABLE OF CONTENTS 1. Safety Instruction 2. Technical Specification 3. How To Set The Unit The following points are important for safety as well as for the smooth installation and 3.1 Control Panel performance of the unit.
- Page 4 4.5 DMX512 Connection 4.4 DMX512 Configuration The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. DMX-512 Configuration CHANNEL 1 CHANNEL 2 CHANNEL 3 Barrel Rotation Laser Diode ON/OFF 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. 2.
-
Page 5: Technical Specification
2. Technical Specification 3. How To Set The Unit 3.1 Control Panel Power supply - AC 120V~60Hz - AC 230/240/250V~50/60Hz Laser diode - Green 4.9mW laser diode x 1 - Red 4.9mW laser diode x 2 Movement - Pan: 180° scan. - Barrel: 360°... - Page 6 4.2 Easy Controller 4. How To Control The Unit The easy remote control is used only in master/slave mode. By connecting to the 1/4” You can operate the unit in three ways: microphone jack of the first unit, you will find that the remote control on the first unit will control 1.
-
Page 7: Main Function
3.2 Main Function DMX512 Address Setting To select any of the given functions, press the MENU button up to when the required one is Press the MENU button up to when the is showing on the display. Pressing ENTER showing on the display. Select the function by ENTER button and the display will blink. Use button and the display will blink. - Page 8 Display Inversion It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to when the is blinking on the display. Use the ENTER button to change to the mode (display inversion), It will automatically store after 8 seconds. Or press the ENTER button again return to the mode (display normal).
