788T/788T-SSD User Guide and Technical Information
8) The Input Settings Window is where changes are made to input parameters.
For example, press the TONE key to toggle Phantom Power (Choose 48V for mi-
crophones). Turn the Multi-Function Rotary Switch to adjust the High-Pass Filter
Frequency.
MENU
HDD
INPUTS MUST BE ROUTED TO TRACKS FOR RECORDING.
9)
From the Input Settings Window, press the PLAY key to enter Input-to-Track Rout-
ing. Inputs can be assigned to any Track. The Rewind and Fast-Forward keys route
inputs to Track L and R, respectively. Turn the Multi-Function Rotary Switch to
move among Tracks A - X2. Push in on the rotary switch to route the input to the
track. Refer to the 788T User Guide for details on pre- and post-fade routing. Press
PLAY again to return to the Input Settings Window.
MENU
HDD
Press PLAY to enter
Input-to-Track routing.
Press again to exit.
Return to the Main Display.
10)
Momentarily move the Input Selector Switch again.
Press the MENU key to enter the Setup Menu.
11)
The Setup Menu allows you to confi gure various options, including Sampling Rate,
Bit Depth, Time Code, etc. Navigate through the Setup Menu by turning the Multi-
Function Rotary Encoder. Refer to the 788T/788T-SSD User Guide for Setup Menu
details.
6
v. 2.16 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Press adjacent key to change the parameter.
MENU
HDD
Turn the Multi-Function Rotary Switch
Press REW to route to
Track L, Press FF to
route to Track R. Use the
Multi-Function Rotary
Switch to route to Tracks
A - X2.
