Names and Functions

The navigation system can be operated by pressing a button on the panel (panel button) or
selecting a button displayed on the screen (on-screen button).
Panel button
1. POWER/VOLUME dial:
2. LOAD/EJECT button:
3. SOURCE button:
4. SEEK/TRACK button:
5. SCAN button:
On-screen button
Turn the audio unit off by pressing the dial. The volume can be
adjusted by turning the dial.
CD loading and ejection. If the display is left in the lowered
position for a certain period of time, a beep sound is heard and
the display closes automatically.
Used to change the audio source.
• and on-screen buttons : FM/AM broadcast
reception.
• on-screen button : CD mode
• on-screen button : Satellite radio
• and on-screen buttons : Image and Sound playback
is possible using a portable video player connected to an
external input terminal.
Sound playback is possible using an audio player connected
to an external input terminal.
AUX1: External sound
AUX2: External image & sound (if equipped)
• on-screen button: iPod mode
• on-screen button : BT-Audio mode
Performs tuning (short press) and searching (long press) in
FM/AM mode, Performs track skip (short press) and fast-
foward/reverse (long press) in CD mode.
Performs scanning operation in FM/AM, CD and Satellite radio
modes.
Panel button
*1
*1
