P-660HN-T1H
802.11n Wireless ADSL2+ 4-port
Gateway
Firmware v3.40
Edition 2, 8/2010
DEFAULT LOGIN DETAILS
IP Address:
Password:
www.zyxel.com
http://192.168.1.1
1234
Copyright 2010
ZyXEL Communications Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-660HN-T1H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZyXEL Communications P-660HN-T1H

Summary of Contents for ZyXEL Communications P-660HN-T1H

  • Page 1 P-660HN-T1H 802.11n Wireless ADSL2+ 4-port Gateway Firmware v3.40 Edition 2, 8/2010 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 Password: 1234 Copyright 2010 ZyXEL Communications Corporation www.zyxel.com...

  • Page 2: Top Panel

    Device Panels Top panel POWER LAN1-4 WPS/ INTERNET WLAN WPS/WLAN BUTTON Rear panel ON/OFF POWER DSL PORT LAN PORT 1-4 RESET...

  • Page 3: Photo Frame

    IEEE 802.11n wireless capability. It allows wired and wireless clients to safely access the Internet. Photo Frame You can also use the P-660HN-T1H as a photo frame for a picture of 4x6 inches. 1. Remove the clear, plastic cover by gently pulling on the tab at the right-hand bottom of the device’s front panel.

  • Page 4: Hardware Connections

    Hardware Connections This section shows you how to set up your P-660HN-T1H. 1. DSL: Use a telephone wire to connect your P-660HN-T1H’s DSL port to a telephone jack (or to a splitter, if one is already installed). 2. LAN: Use an Ethernet cable to connect a computer to a LAN port for initial configuration and/or Internet access.

  • Page 5: Status Page

    P-660HN-T1H • The POWER light blinks while your P-660HN-T1H starts up and stays on once it is ready. The DSL light is on when the P-660HN- T1H has a DSL connection, and the WLAN light is on when the wireless LAN is ready. The INTERNET light is on when you are able to access the Internet and blinks when the P-660HN-T1H is sending or receiving data.
  • Page 6 P-660HN-T1H to finish detection. If any other screens appear, follow the directions in the screen. If the web page opens correctly, your P-660HN-T1H is ready for you to use. Skip the rest of this procedure. If the web page does not open, follow the rest of the steps. You should have the information provided by your ISP.
  • Page 7 3. Enter the default password 1234 and click Login. 4. Click Go to Wizard Setup. Then click Apply. 5. Click INTERNET/WIRELESS SETUP. Wait while your P-660HN-T1H tries to detect your DSL connection. 6. Follow the directions in the wizard. Do not change default settings if...

  • Page 8: Troubleshooting

    LAN port, follow these steps. a. Check the lights on the front panel. If they are different from what is described on page 5, make sure the P-660HN-T1H is correctly connected. If the lights are still different, turn off the device, wait a few seconds, and turn it on again.
  • Page 9 P-660HN-T1H b. Make sure your P-660HN-T1H and your computer are using the same wireless and wireless security settings. Viewing Certification(s) • Go to www.zyxel.com. • Select your product from the drop-down list box on the ZyXEL home page to go to that product's page.
